Hospital lighting D series

laboratorybuilt-inceiling-mounted

Overview
Extra-slim downlights from the D12W, D15W, D18W and D24W range complete LUCISBIO’s portfolio for office and general lighting. They provide an energy-efficient alternative to fluorescent fixtures while maintaining a low-profile installation depth.

Key features

• Extra-slim 12 mm depth
• Energy-efficient LED alternative to fluorescent lights
• Rated lifetime: 50,000 hours (L70/L80 depending on model)
• Multiple lumen outputs and diameters available

LED DOWNLIGHT FOR OFFICES AND GENERAL LIGHTING
Design
The series features a clean aesthetic with a white painted aluminium frame and PMMA diffuser, enabling discreet integration in ceilings and partitions.

Savings
Low consumption and a long service life (50,000 hours) reduce operating costs and maintenance frequency in commercial installations.

Versatility
With a 12 mm mounting depth, these downlights are suitable for shallow ceilings and partition installations. Available in Cool White (6000 K) and Neutral White (4000 K), they deliver uniform, comfortable illumination for office and general lighting applications.

Material
White painted aluminium frame with PMMA diffuser.

Mounting
Retention by two spring-loaded side arms for quick recessed installation.

Power supply
Units are supplied with an external driver to be connected to 230 VAC – 50 Hz mains.

Downloads

• Downlight - FTv1 - LUCISBIO (documentation available)

Technical specifications

• Dimensions Ø x H: 170 x 12 / 195 x 12 / 225 x 12 / 300 x 12 mm
• Cut-out Ø: 150 / 170 / 205 / 275 mm
• Lifetime (L70/L80): 50,000 hours
• Colour temperatures: Cool White 6000 K (BF), Neutral White 4000 K (BN)
• Luminous flux: 1200 / 1500 / 1800 / 2400 lm
• Power: 12 / 15 / 18 / 24 W
• IP rating: IP54
• Operating temperature: -35 °C to +60 °C
• UGR: < 19
• Beam angle: 180°
• Electrical insulation: Class II
• Warranty: 2 years
