Overview
Compact LED spotlights D03W, D06W and D09W for recessed mounting in ceilings or partitions. They provide complementary, uniform lighting suitable for offices and general illumination.

Highlights

• Compact design
• Designed for ceiling and partition integration
• Lifetime: 50 000 hours (L80)
• Available in multiple lumen outputs and dimensions

LED SPOTLIGHT FOR OFFICES AND GENERAL LIGHTING
Design
With a clean aesthetic, the D03W, D06W and D09W complete the LUCISBIO range of lighting solutions while maintaining visual consistency.

Energy and maintenance
Easy to install and energy-efficient, these spotlights contribute to lower operating costs with a rated lifetime of 50 000 hours (L80).

Versatility
Only 12 mm deep, they integrate into ceilings and partitions. Available in Cool White and Neutral White, the D03W, D06W and D09W deliver a comfortable and effective luminous effect for fitted rooms.

Material
White painted aluminium frame with a PMMA diffuser.

Mounting
Two spring-loaded side arms secure the spotlight into the cut-out.

Power supply
The spotlights are supplied with an external driver to be connected to the 230 VAC, 50 Hz mains.

Technical specifications

• Dimensions Ø x H: 90 x 12 / 120 x 12 / 150 x 12 mm
• Cut-out Ø: 70 / 105 / 135 mm
• Lifetime (L80B10): 50 000 hours
• Colour temperatures: Cool White 6000 K (BF), Neutral White 4000 K (BN)
• Luminous flux: 300 / 600 / 900 lm
• Power: 3 / 6 / 9 W
• IP: 54
• Operating temperature: -35°C to +60°C
• UGR: < 19
• Beam angle: 180°
• Electrical class: Class II
• Warranty: 2 years
