Reciprocating laboratory shaker RS-01

with piston roddigitalfor production

Product overview
RS-01 combines a thermoelectric cooling system with a motor-driven shaking and pressing mechanism to deliver controlled low-temperature mixing of bagged liquids. The unit maintains stable temperatures and applies adjustable compression and shaking to ensure uniform mixing for chilled formulations and cold-chain sample handling in laboratory and production settings.

Key features

• Thermoelectric cooling with precise temperature control: stable range 2–8℃.
• Adjustable shaking/pressing frequency for uniform mixing: 30–110 cycles/min.
• Cold plate footprint 220×160 mm compatible with culture and sample bags.
• Compact benchtop dimensions (356×380×580 mm) and 25 kg weight for easy integration.

Applications

• Clinical and research laboratories: chilled sample and reagent preparation.
• Pharmaceutical formulation and small-batch chilled product preparation.
• Biotechnology and cell/gene therapy: mixing and low-temperature handling of bagged cultures and formulations.
• Food R&D for low-temperature processing and product development.

Technical specifications

• Dimensions: 356×380×580 mm.
• Cold plate dimensions: 220×160 mm.
• Shaking frequency: 30–110 cycles/min.
• Weight: 25 kg.
• Power supply: AC 220 V / 50 Hz.
• Power: 200 W.
• Temperature range: 2–8℃.
