Elbow orthosis ROM-R

extensionflexionarticulated

Product description
Thuasne ROM‑R is a lightweight, low‑profile postoperative articulated elbow brace designed to provide immobilisation, stabilisation and controlled range of motion for postoperative patients. It integrates a full range‑of‑motion drop‑lock hinge (flexion 0°–120°, extension up to 105° in 15° increments) plus two telescopic, bendable side hinges. Customisable, contourable cuffs and tool‑free telescopic bendable uprights allow rapid, personalised fitting for adult patients in a postoperative care pathway.

Key features

• Postoperative articulated elbow brace with ROM control
• Full range‑of‑motion drop‑lock hinge: 17 flexion positions (0° to 120°) and extension up to 105° in 15° increments
• Two telescopic, bendable side hinges for stabilisation
• Immobilisation positions: 0°, 15°, 30°, 45°, 60°, 90°
• Tool‑free telescopic bendable uprights for bedside adjustment
• Customisable, contourable cuffs for personalised fit
• One‑size‑fits‑all design with colour‑coded touchpoints for hinge setting
• Colour: Black / Dark blue

Indications

• Postoperative elbow immobilisation and controlled ROM management
• Conservative treatment of elbow dislocation/luxation
• Stable or internally fixed fractures of the distal humerus or proximal radius/ulna

Contraindications

• Do not use without a confirmed diagnosis
• Do not use in unstable or surgical fractures requiring operative management
• Do not use for fractures outside the device's area of action (e.g. proximal humerus, distal radius/ulna)
• Do not apply directly on broken skin or open wounds without appropriate dressing
• Do not use in cases of impaired lymphatic drainage
• Do not use in patients with known allergy to any component

Materials

• Textile: polyester 25% - polyamide 60% - polypropylene 15%
• Rigid components: aluminium 60% - steel 10% - stainless steel 10% - polyamide 20%

Patient profile

• Adult patients
• Post‑surgery / postoperative care pathway

Legal & regulatory
The device is a Class I medical device, CE marked in accordance with Regulation (EU) 2017/745. Follow the product instructions for use.

Technical specifications

• Model name: ROM‑R Elbow
• Brace type: Postoperative articulated elbow brace with ROM control
• Range of motion (flexion): 0° to 120° (15° increments) — 17 flexion positions
• Range of motion (extension): up to 105° (15° increments)
• Immobilisation positions: 0°, 15°, 30°, 45°, 60°, 90°
• Hinges: 1 full range‑of‑motion drop‑lock hinge + 2 telescopic/bendable side hinges
• Adjustment: Tool‑free telescopic bendable uprights; colour‑coded touchpoints
• Size: One‑size‑fits‑all
• Primary materials: polyester, polyamide, polypropylene, aluminium, steel, stainless steel
• Colour: Black / Dark blue
