Catheter guidewire Astato XS

hydrophilic

Overview
Astato XS guidewires feature a tapered, straight tip optimized for lesion penetration and controlled wire escalation. Two tip-load variants enable stepwise escalation strategies during complex endovascular procedures.

Product Spec (summary)

• Tip Load: 20 gf (Astato XS 20) / 40 gf (Astato XS 40)
• Tip Shape: Straight
• Radiopaque Length: 17 cm
• Coating: Hydrophilic (Uncoated Ball Tip)
• Usable Length: 180 cm (Astato XS 20) / 200 cm (Astato XS 40) / 300 cm (both)
• Outer Diameter: 0.20/0.36 mm (0.008/0.014") for XS 20; 0.23/0.36 mm (0.009/0.014") for XS 40
• Coating Length: 17 cm (XS 20) or 60 cm (XS 40)
• Coil Length: 17 cm

Category

• #Guidewire
• #0.014"

Order Information (table)
Columns: Product Name | Catalog No. | Tip Shape | Usable Length | Outer Diameter | Coating | Coating Length | Coil Length | Radiopaque Length
Astato XS 20 | PAGH143092 | Straight | 180 cm | 0.20/0.36 mm (0.008/0.014") | Hydrophilic (Uncoated Ball Tip) | 17 cm | 17 cm | 17 cm
Astato XS 20 | PAGH143392 | Straight | 300 cm | 0.20/0.36 mm (0.008/0.014") | Hydrophilic (Uncoated Ball Tip) | 17 cm | 17 cm | 17 cm
Astato XS 40 | PAGHW143094 | Straight | 200 cm | 0.23/0.36 mm (0.009/0.014") | Hydrophilic (Uncoated Ball Tip) | 60 cm | 17 cm | 17 cm
Astato XS 40 | PAGHW143394 | Straight | 300 cm | 0.23/0.36 mm (0.009/0.014") | Hydrophilic (Uncoated Ball Tip) | 60 cm | 17 cm | 17 cm

Notes
Astato is a trademark or a registered trademark of ASAHI INTECC CO., LTD. in Japan and other countries. The tip load values are company-standardized test values representing the force applied at the tip; actual device performance may vary between individual devices.

Technical specifications

• Brand: ASAHI INTECC
• Commercial name: Astato XS
• Tip Load: 20 gf (Astato XS 20) / 40 gf (Astato XS 40)
• Tip Shape: Straight
• Radiopaque Length: 17 cm
• Coating: Hydrophilic (Uncoated Ball Tip)
• Usable Lengths: 180 cm, 200 cm, 300 cm
• Outer Diameters (catalog): 0.20/0.36 mm (0.008/0.014") for XS 20; 0.23/0.36 mm (0.009/0.014") for XS 40
• Coating Length (catalog): 17 cm (XS 20) or 60 cm (XS 40)
• Coil Length: 17 cm
• Catalog numbers: PAGH143092, PAGH143392, PAGHW143094, PAGHW143394
