Tattoo removal laser VN30

rubyNd:YAG

Product Overview
Laser tattoo removal uses selective absorption of wavelengths (1064 nm, 532 nm and 1320 nm) by tattoo pigments. Q‑switched Nd:YAG pulses fragment pigment particles, which are then cleared by the body's immune system. The wavelengths minimize energy absorption by surrounding skin, enabling targeted pigment removal with limited impact on normal tissue.

Key Information

• Type: Tattoo Removal
• Theory: Q‑Switched Nd:YAG Laser
• Application: Beauty clinics, salons
• Mobility: Portable
• Model: VN30
• Brand: VCALASER

Uses / Indications

• Removal of multi‑colored tattoos (black, blue, brown, red).
• Removal of cosmetic tattoos: eyebrows, eyeliner, lips.
• Treatment of pigmented lesions: freckles, age spots, birthmarks, nevus, sunspots, post‑inflammatory pigmentation.
• "Black Doll" mode: indications include superficial whitening, epidermal rejuvenation, acne scar management and pore minimization.

Specification Table

• Model: VN30
• Brand: VCALASER
• Laser Type: Q‑Switched Nd:YAG laser
• Wavelengths: 1064 nm, 532 nm, 1320 nm (Black Doll)
• Pulse energy: 1000 mJ
• Pulse duration: 10 ns
• Pulse repetition rate: 1–6 Hz (adjustable)
• Treatment area / spot size: 1 mm² – 10 mm²
• Cooling: Air cooling and closed‑loop de‑ionized distilled water cooling (water included)
• Voltage: 110/220 V ±10%, 50/60 Hz
• Indicator light: Ruby indicator

Additional Description
The device supports multi‑wavelength treatment modes and adjustable pulse repetition rate to target different pigment colors and lesion depths. Q‑switched Nd:YAG energy is strongly absorbed by blue and black melanin, fragmenting particles until they can be metabolized or excreted by lymphatic clearance, allowing effective tattoo and pigmentation removal with minimal collateral tissue damage.
