Thermal transfer label applicator printer BP12-CR1500-KITEU

barcode labelfor bar code labelsmonochrome

Product overview
The Brady® BBP®12 label printer kit combines versatile thermal-transfer printing with the CR1500 omnidirectional barcode reader to streamline labeling and scanning workflows in industrial environments. The kit supports both continuous and die-cut labels and is designed for fast media changes and reliable barcode capture, including high-density and wide-field codes.

Benefits

• Print a wide range of label types from a single device to reduce SKUs, downtime and training needs.
• Supports over 800 label varieties and small-core media for fast installation and changeover.
• CR1500 reads 1D and 2D codes reliably in challenging conditions, reducing rescans.
• Compact footprint and rugged design suitable for shop-floor and benchtop use.
• Centering ribbon spindle reduces ribbon wrinkles and improves print consistency.

Key features

• Label media: Continuous and Die-cut
• Applications: Asset tracking; Barcode labelling; Inventory & inspection; Laboratory labelling; Wire & cable labelling
• Print technology: Thermal Transfer
• Colour capability: Monochrome
• Resolution: 300 dpi
• Max. label width: 116.84 mm
• Max. print width: 105.41 mm
• Print speed: Up to 101.60 mm/s
• Memory: 128 MB Flash, 64 MB SDRAM; SD up to 32 GB
• Connectivity: Ethernet, Serial, USB (PC interface)
• Power: AC adaptor 110-240 V; lithium-manganese battery supplied

What’s included
This kit ships in a cardboard box and includes: BBP12 printer, CR1500 barcode reader, unwinder, USB cable, power cord, Brady Workstation Basic Suite (CD), Quick Start Guide and a blank ribbon core.

Technical specifications

• Article Number: 324704
• Order reference / Part number: BBP12-CR1500-KITEU
• Quantity per pack: 1 Kit / Box
• Minimum order quantity: 1
• Brand / Trade name: Brady® / BBP®12
• Supported materials: Paper; Direct Thermal Paper; Polyester and laminated/metalised variants; FreezerBondz™, StainerBondz™; Polyimide; Polyolefin; Polypropylene; Vinyl; Nylon cloth; PVF; Self-laminating materials
• Dimensions (W x H x D): 202.95 mm x 190.50 mm x 259.33 mm
• Weight: 2.3 kg
• Core diameter: 25.40 mm
• Display size: 58.42 mm (320 x 240 pixels)
• Min label height: 10.00 mm (typical)
• Max roll outer diameter: 127.00 mm
• Max label thickness: 0.19 mm
• Print rotation: 0°, 90°, 180°, 270°
• Programming language / emulation: Built-in ZPL emulator
• Media sensors: Black mark, gap sensor, head open, ribbon end
• Operating temp.: 5°C - 40°C; Storage: -40°C - 70°C
• Operating humidity: 25% - 85% (non-condensing)
• Barcode symbologies supported: Aztec, DataMatrix, GS1 DataMatrix, QR Code, PDF417, MicroPDF417, MaxiCode, Code 128, GS1-128, Code 39, EAN-13, EAN-8, UPC-A, UPC-E, Interleaved 2 of 5, ITF-14 and others
• Software compatibility: Brady Workstation; Windows drivers for 3rd party software
• Warranty: 1 year
• Regulatory / compliance: CE, cUL, EAC, RoHS (2011/65/EU with exemptions), UL
• UNSPSC: 45101519
• REACH SVHC status: Part does not contain an SVHC; Candidate List Date: 04 February 2026
