Instrument tray lid YWD-9005

siliconestainless steelperforated

Product: Mesh Tray Lid YWD-9005 — perforated lid for mesh instrument trays, size 255 x 120 mm, stainless steel 304, perforation 2.5 mm (22 swg), mesh 5.5 x 5.5 x 1.2 mm.

Applications:

• Designed for handling, storage, washing and sterilization of surgical and dental instruments.
• Allows rapid drying after automatic washing and sterilization cycles.
• Protects instrument tips and edges during transport and storage.

Key features:

• Material: stainless steel 304, non-magnetic.
• Electropolished surface option for enhanced cleanliness.
• Rounded, deburred edges to protect instruments and staff.
• Easy-to-lock lid design with pull-up, stackable handles.
• Perforated sidewalls to increase liquid and gas flow while protecting sharp edges.
• Perforation size: 2.5 mm (22 swg); mesh: spotted 5.5 x 5.5 x 1.2 mm.
• Available in multiple sizes and frame options: single frame, double frame, detention frame lids.
• High durability: withstands 1000+ sterilization cycles without loss of shape or function.
• All trays and lids are stackable; compatible with common accessories (silicone mats, inserts, tags).

Sizes (table):
YWD-9004 | 255 x 245
YWD-9005 | 255 x 120
YWM-9008 | 250 x 240

Additional information:

• Surface finishes available: mirror, luster, satin, brushed, colored.
• Manufacturing: laser cut; electropolished finish available.
• Stackable design for efficient storage and sterilizer loading.

Technical specifications:

• Model / Denomination: YWD-9005 (Mesh Tray Lid)
• Material: Stainless steel 304, non-magnetic.
• Perforation size: 2.5 mm or 22 swg.
• Mesh specification: spotted 5.5 x 5.5 x 1.2 mm.
• Available sizes: YWD-9004 (255 x 245), YWD-9005 (255 x 120), YWM-9008 (250 x 240).
• Surface finishes: mirror, luster, satin, brushed, colored.
• Edge treatment: rounded and deburred edges.
• Handles: pull-up and stackable handles.
• Frame options: single frame, double frame, detention frame lids.
• Compatibility: Designed for automatic washing and sterilization processes.
• Durability: Designed to withstand 1000+ sterilization cycles without loss of shape or functionality.
• Manufacturing process: laser cut; electropolished surface option.
• Stackability: All trays and lids are stackable; suitable for instrument handling, storage, washing and sterilization.
