Presence detector MEAS AD-101
for medical applicationsultrasoniccompact

Presence detector - MEAS AD-101 - TE Connectivity - for medical applications / ultrasonic / compact
Presence detector - MEAS AD-101 - TE Connectivity - for medical applications / ultrasonic / compact
Add to favorites
Compare this product

Characteristics

Tested parameter
presence
Applications
for medical applications
Technology
ultrasonic
Configuration
compact
Other characteristics
non-invasive

Description

Product Name
  • 071-06402 — ABD, AD-101, COMPACT ASSY, 6MM


Brand / Series
  • MEAS
  • Series: MEAS AD-101


Identifiers
  • TE Internal #: 10217758-00
  • TE Internal Description: ABD, AD-101, COMPACT ASSY, 6MM
  • TCPN / Catalog Number: 071-06402


Product Type
  • Ultrasonic sensor — Air Bubble / Air-in-line Detector
  • Non-Invasive style (clamp-on / external sensing)


Electrical & Functional
  • Input Voltage (VDC): 6 – 24
  • Output Type: Open Collector


Mechanical / Physical
  • Cable Length: 0.31 m [1 ft]
  • Sensor diameter / assembly: 6 mm (COMPACT ASSY)


Operating Conditions
  • Operating Temperature Range: 0 – 65 °C [32 – 149 °F]


Available Documents (names only)
  • 3D_CVM_CVM_10217758-00_E.pdf (Customer View Model)
  • ENG_CVM_CVM_10217758-00_E.2d_dxf.zip
  • ENG_CVM_CVM_10217758-00_E.3d_igs.zip
  • ENG_CVM_CVM_10217758-00_E.3d_stp.zip
  • ENG_DS_AD101_Air_Bubble_Detector_A1.pdf (Datasheet)


Notes
  • Non-invasive ultrasonic air bubble / air-in-line detector intended for integration; listed as Special Order on the product page and marked noncancelable/nonreturnable.
  • Distributor listings on the product page indicate available stock and distributor pricing, which vary by distributor and quantity.


Characteristics / Technical Specifications
  • Product family: MEAS AD-101
  • Type: Air Bubble / Air-in-line Detector (Ultrasonic)
  • Style: Non-Invasive
  • Input Voltage: 6 – 24 VDC
  • Output: Open Collector
  • Cable Length: 0.31 m (1 ft)
  • Sensor diameter / assembly: 6 mm (COMPACT ASSY)
  • Operating Temperature: 0 – 65 °C (32 – 149 °F)
  • TE Internal Number: 10217758-00
  • Catalog / TCPN: 071-06402
