Lat pulldown gym station PL4002

horizontal pulllimited mobility userswith free weights

Product description
Concentrate work on the lower back with the PL4002 from Etenon Fitness. Plate-load low-row machine designed to develop dorsal and lumbar musculature. Ergonomic geometry ensures natural, fluid movement and a low row angle for bilateral and unilateral execution to target lats and lower-back muscles.

Usage level
Intensive (commercial/club use).

Technical specifications

• Frame: Q235 steel oval tube 100 x 50 mm, 3 mm thickness.
• Welded structure with matte black powder-coat finish for increased resistance.
• Machine biomechanics designed for accessibility across user profiles.
• Upholstery: matte black FOAM filling, antibacterial and fire-retardant; density 200 kg/m3.
• Industrial bearings and high-quality fasteners.
• 4 chrome plate holders with sandblasted finish.
• Aluminium ergonomic grips for secure contact.
• Height-adjustable seat to adapt to different users.
• Instructional pictogram showing correct posture and muscles involved.
• Soft non-slip PVC base plugs secured with screws to prevent detachment.

Dimensions and Weight

• Length: 139 cm
• Width: 128 cm
• Height: 165 cm
• Machine weight: 146 kg
• Maximum load capacity: 200 kg (100 kg per plate holder)

Documentation
Technical data sheet available (see attached product documentation).

Characteristics / technical specifications

• Structure material: Q235 steel oval tube 100 x 50 x 3 mm, welded.
• Finish: matte black powder paint.
• Upholstery: matte black FOAM, antibacterial, fire-retardant; density 200 kg/m3.
• Bearings & fasteners: industrial bearings and high-quality screws.
• Plate holders: 4 chrome holders with sandblasted finish.
• Grips: aluminium ergonomic grips.
• Seat: height-adjustable.
• Stability: soft non-slip PVC base plugs fastened with screws.
• Dimensions: 139 x 128 x 165 cm (L x W x H).
• Weight: 146 kg.
• Max load capacity: 200 kg total (100 kg per plate holder).
