Resin dental material RS-C2-CWPU-01

for dental bridgesfor dental crownsfor 3D printing

Overview
Castable Wax Resin is a 20% wax-filled SLA resin formulated for dental casting and pressing workflows. It produces highly accurate 3D-printed patterns with a smooth surface finish, clean burnout and near-zero ash content (TGA: 0.0 - 0.1%), enabling precise copings, substructures, full-contour crowns and removable partial denture frameworks. Formlabs Castable Wax Resin is optimized for patterns used in casting and pressing dental prosthetics.

Applications

• Patterns for casting and pressing crowns, bridges and removable partial dentures (RPDs)
• Patterns for copings, substructures and full-contour crowns
• Removable partial denture frameworks

Key features

• 20% wax-filled formulation for improved burnout
• Captures intricate features and provides a smooth surface finish
• Zero ash content (TGA: 0.0 - 0.1%) for clean casting
• Optimized for casting and pressing workflows

Material properties (selected)
Ultimate Tensile Strength: 12 MPa
Tensile Modulus: 220 MPa
Elongation: 13%
Temperature @ 5% Mass Loss: 249 ºC
Ash Content (TGA): 0.0 - 0.1%

Additional product details

• Compatible build platforms: Form 4 Build Platform; Form 4 Flex Build Platform; Form 3 Build Platform; Form 3 Build Platform 2; Form 3 Stainless Steel Build Platform; Form 3L Build Platform; Form 3L Build Platform 2L; Form 4L Build Platform; Form 4L Flex Build Platform
• Compatible tanks: Form 2 LT Tank; Form 2 Resin Tank (PDMS); Form 3 Resin Tank V2.1; Form 3L Resin Tank V3; Form 4 Resin Tank
• Print technology: SLA
• Compatible printers: Form 4B, Form 4BL, Form 3B, Form 3BL
• Color: Purple
• Primary applications: Patterns for Casting & Pressing

Bulk order discounts (volume → discount)

• 30 L → 15%
• 60 L → 20%
• 120 L → 25%
• 240 L → 30%
• 1,000 L → 35%
• 2,000 L → 40%
• 3,000 L → 45%

Workflow notes

• Washing: remove excess resin on part surfaces using alcohol or ether wash (follow recommended wash procedures)
• Curing: follow recommended curing settings for the resin to achieve final properties

Technical specifications

• Commercial name: Castable Wax Resin
• Brand: Formlabs
• Print technology: SLA
• Compatible printers: Form 4B, Form 4BL, Form 3B, Form 3BL
• Compatible build platforms: multiple Form 3 / Form 3L / Form 4 / Form 4L build platforms
• Compatible tanks: Form 2 LT Tank; Form 2 Resin Tank (PDMS); Form 3 Resin Tank V2.1; Form 3L Resin Tank V3; Form 4 Resin Tank
• Color: Purple
• Ultimate Tensile Strength: 12 MPa
• Tensile Modulus: 220 MPa
• Elongation: 13%
• Temperature @ 5% Mass Loss: 249 ºC
• Ash Content (TGA): 0.0 - 0.1%
