HPLC valve 7725I series

manualstainless steelhigh-pressure

Product overview
The 7725i-188 syringe injection valve is a manual front-loading, analytical-grade injection valve engineered for high-pressure instrumentation. It uses Make-Before-Break (MBB®) architecture to maintain continuous flow between LOAD and INJECT positions, reducing disturbance during switching. Rated to 600 bar (8700 psi), it provides a compact 2-position, 6-port configuration suitable for demanding laboratory and process-analytical applications.

Features

• Manual front-loading injection for controlled sample introduction
• Make-Before-Break (MBB®) architecture for uninterrupted flow between LOAD and INJECT
• 2 positions, 6 ports for sample and carrier routing
• High pressure rating: up to 600 bar (8700 psi)
• Optimized for 1/16" OD tubing; coned 10-32 port configuration
• Stainless steel construction for compatibility with common analytical solvents

Specifications

• Model: 7725i-188
• Material: Stainless steel
• Ports: 6
• Positions: 2
• Maximum pressure: 600 bar (8700 psi)
• For tubing OD: 1/16"
• Thread/port configuration: coned 10-32

Applications

• HPLC/analytical injection systems
• Process analytical instrumentation and sampling
• Laboratory automation requiring high-pressure sample introduction
• Direct replacement in systems using 1/16" tubing and 10-32 coned fittings
