Ceiling-mounted surgical light FY-720

LEDfor operating rooms2-arm

Description
Ceiling-mounted 720 mm LED surgical lamp designed to provide stable, uniform illumination for operating rooms. Compact lamp head with 6-lens optical system and Osram LED light source, suitable for a range of surgical procedures.

Core Highlights

• Automatic shadow compensation for consistent field illumination
• 6-lens optical system for uniform, focused light
• Smart touch control for intuitive operation
• Imported Osram LEDs with long service life
• High color rendering for accurate tissue visualization (Ra ≥97)
• Low heat emission to enhance patient and staff safety
• Wide input voltage (AC 100–240V) for global compatibility
• Flexible double arm with extended reach for precise positioning
• 2-year warranty

Technical Parameters

• Model: FY-720 (720 Ceiling)
• Control: Smart touch control (optional touch control ring)
• Optical system: 6-lens unit
• Function: Automatic shadow compensation
• Lamp head diameter: 720 mm
• Light source: LED, lifespan ≥60,000 hrs
• LED bulbs: Imported Osram, 140 pcs
• Brightness: 40,000–160,000 Lux, 10-step adjustable
• Lighting focus: 120–350 mm, adjustable via touch control or central handle
• Color temperature: 3000K–5000K, 5-step adjustable
• Color rendering index Ra: ≥97; R9/R13/R15: ≥95
• Lighting depth (L1+L2): ≥1500 mm
• Area temperature rise: < 0.5 ℃
• Power consumption: 100 VA
• Power input: AC 100–240V 50/60Hz, switching power supply
• Central handle: detachable; optional extra touch control ring
• Arm reach: 800 + 900 mm
• Warranty: 2 years

Product Features

• Automatic shadow compensation maintains stable brightness when partially obstructed
• 6-lens optical unit produces an even, high-quality light spot
• Smart touch control enables rapid adjustments during procedures
• Imported Osram LED chips ensure reliability and long life
• 10-level brightness adjustment to match surgical needs
• Adjustable focus via touch panel or detachable central handle
• 5-level color temperature adjustment for visual comfort
• Ultra-high color rendering for true tissue color reproduction
• Extra-deep lighting depth suitable for deep-cavity operations
• Minimal temperature rise at the surgical site
• Energy-efficient with stable wide-voltage supply
• Detachable sterile handle; optional touch control ring available
• Flexible double arm enables extensive movement and precise positioning
• 2-year warranty for dependable clinical use

Application
Intended as the primary illumination source for operating theatres and procedure rooms in hospitals, clinics and other medical institutions.

Specifications

• Model: FY-720 (720 Ceiling)
• Lamp head diameter: 720 mm
• Optical system: 6-lens unit
• Light source & lifespan: Osram LED, ≥60,000 hrs
• Bulb quantity: 140 pcs
• Brightness: 40,000–160,000 Lux (10 steps)
• Focus range: 120–350 mm (adjustable)
• Color temperature: 3000K–5000K (5 steps)
• Color rendering: Ra ≥97; R9/R13/R15 ≥95
• Lighting depth: ≥1500 mm
• Area temperature rise: <0.5 ℃
• Power consumption: 100 VA
• Input voltage: AC 100–240V 50/60Hz
• Arm reach: 800 + 900 mm
• Control: Smart touch control (optional touch control ring)
• Warranty: 2 years
