Headband-type surgical loupe AENS

with flip-up systemErgowith headlamp

PRODUCT FEATURES

• Adjustable interpupillary distance and working distance
• Flexible purchase model: buy only the lenses you need; upgrade anytime without replacing the whole unit
• 4-in-1 angled variable-magnification magnifier (multiple magnification options available)
• Flip-up design for quick switch between magnified and normal vision
• Magnetic interchangeable lenses for flexible magnification
• Adjustable IPD range: 50–70 mm

PRODUCT INTRODUCTION

• Modular magnification system with magnetic snap-on interchangeable lenses enabling easy change of magnification without tools
• Flip-up mechanism lets user switch between magnified view and normal vision quickly and conveniently
• Asynchronous interpupillary distance adjustment method for fine alignment between users
• Compatible with various clip-on headlights for combined illumination and magnification

OPTICAL SPECIFICATIONS (table)
Magnification: 3.5X 4.5X 5.5X 6.5X
Working Distance: 360–600 mm 360–600 mm 360–600 mm 360–600 mm
Field of View: 70–90 mm 60–80 mm 50–70 mm 50–70 mm
Depth of Field: 150 mm 100 mm 90 mm 80 mm
Interpupillary Distance Adjustment Range: 50–70 mm 50–70 mm 50–70 mm 50–70 mm


ADDITIONAL HIGHLIGHTS

• Flexible purchase and upgrade strategy reduces initial cost and enables long-term scalability
• Suitable for multi-user environments (adjustable IPD and headband design support different users in clinics or hospitals)
• Magnetic interchangeable lenses allow fast on-site changes of magnification levels
• Combination-ready with various clip-on headlights to provide illumination options

Technical specifications

• Model designation: AENS
• Magnification options: 3.5X, 4.5X, 5.5X, 6.5X
• Working distance: 360–600 mm (all magnifications)
• Field of view: 70–90 mm (3.5X); 60–80 mm (4.5X); 50–70 mm (5.5X & 6.5X)
• Depth of field: 150 mm (3.5X); 100 mm (4.5X); 90 mm (5.5X); 80 mm (6.5X)
• Interpupillary distance (IPD) adjustment range: 50–70 mm
• Interpupillary distance adjustment method: Asynchronous adjustment
• Design: Flip-up head-mounted loupe with magnetic interchangeable lens system
• Purchase model: Modular (purchase lenses separately; upgrade without replacing whole unit)
• Compatibility: Supports various clip-on headlights
