Cooling laboratory incubator KT 170

forced convectionthermoelectricfor scientific research

Benefits

• Safe and reproducible incubation conditions even at high environmental conditions
• Hot air disinfection at 100°C
• Energy efficient, environmentally friendly and secure

Product description
The KT series combines outstanding performance with impressive energy efficiency and environmental friendliness. The cooled incubators of the KT series are state-of-the-art in application and protect the samples.

Important characteristics

• Temperature range: +4 °C to +100 °C
• APT.line™ preheating chamber technology
• Adjustable fan speed
• Electric cooling with Peltier module
• Controller with time-segment and real-time programming
• Display via LCD monitor
• Input via pushbutton/rotary knob
• Inner door made of tempered safety glass
• 2 stainless steel racks (std.)
• Stackable with KT 115
• Class 3.1 independent temperature safety device (DIN 12880) with visual and audible temperature alarm
• Computer interface: Ethernet
• Data recording and USB interface

Data
Article Number: 9020-0289 | 9020-0310
Designation: KT170-230V | KT170UL-120V
Option model: Standard

Performance Data Temperature
Temperature range: 4...100 °C
Temperature uniformity at 37°C: 0.4 ± K
Temperature fluctuation at 37°C: 0.1 ± K
Max. heat compensation at 40°C: 100 W
Recovery time after door was opened for 30 s at 37°C: 3 min

Electrical data
Rated Voltage: 200...240 V | 100...120 V (depending on article number)
Power frequency: 50/60 Hz
Nominal power: 0.8 kW
Unit fuse: 10.0 A
Phase (Nominal voltage): 1~

Dimensions and weights
Interior volume: 163 L
Net weight of the unit (empty): 102 kg
Load per rack: 30 kg
Permitted load: 120 kg
Wall clearance back: 100 mm
Wall clearance sidewise: 240 mm

Housing dimensions (not incl. fittings and connections)
Width net: 860 mm
Height net: 1,025 mm
Depth net: 655 mm

Internal Dimensions
Interior width: 600 mm
Interior height: 765 mm
Interior depth: 355 mm
Inner doors: 1
Unit doors: 1

Environment-specific data
Sound-pressure level: 48 dB(A)
Energy consumption at 25°C: 80 Wh/h
Energy consumption at 37°C: 80 Wh/h

Fixtures
Number of shelves (std./max.): 2/10

Notes
Controller with time-segment and real-time programming; APT.line™ preheating chamber technology; hot air disinfection at 100°C; stackable with KT 115; data recording via USB; Ethernet interface available.

Technical specifications

• Model: KT 170
• Temperature range: +4 °C to +100 °C
• Interior volume: 163 L
• Interior WxHxD: 600 x 765 x 355 mm
• Exterior WxHxD (net): 860 x 1,025 x 655 mm
• Net weight (empty): 102 kg
• Permitted load: 120 kg; load per rack 30 kg
• Heating compensation (40°C): 100 W
• Recovery time after 30 s door opening (37°C): 3 min
• Temperature uniformity at 37°C: 0.4 K; fluctuation: 0.1 K
• Noise level: 48 dB(A)
• Energy consumption: 80 Wh/h (25°C and 37°C reported)
• Electrical: 200...240 V or 100...120 V variants; 50/60 Hz; nominal power 0.8 kW; fuse 10 A
• Cooling: Electric cooling with Peltier module
• Safety device: Class 3.1 independent temperature safety device (DIN 12880) with visual and audible alarm
• Interfaces: Ethernet; USB data recording
• Standard equipment: 2 stainless steel racks; inner tempered safety glass door
