Monitoring camera module e-CAM86_CUMI715C_MOD - Sony® Starvis™ IMX715

digital4KCMOS

Ultra-low light sensitivity Overview e-CAM86_CUMI715C_MOD is an 8MP (4K) ultra-low light camera module. This MIPI camera module is based on a SONY® STARVIS™ IMX715 sensor. The high sensitivity of this camera module helps to capture images in extremely low lighting conditions, which makes it possible to accurately detect and capture objects even in dark scenes. This fixed focus camera module has an S-Mount holder which allows customers to choose and use the lens according to their requirements. Refer pdfDatasheet for complete frame rate details. Key features: 4K camera based on Sony® Starvis™ IMX715 CMOS image sensor Utilizes NVIDIA® Jetson's ISP for image processing Plugs into NVIDIA Jetson AGX ORIN / Xavier development kits High-speed 4-lane MIPI CSI-2 interface S-mount interchangeable lens holder for flexibility to choose a lens as per application requirements Output Format - RAW10/RAW12 Formfactor - 30mmx30mm RoHS Compliant Sensor features: Sensor: IMX715 from SONY® Starvis Focus Type: Fixed focus Chroma: Color Shutter Type: Electronic Rolling Shutter Optical Format: 1/2.8" Output Format: RAW 12 bit / 10bit Pixel Size: 1.45 μm x 1.45 μm Sensor Active Area: 3848(H) x 2168(V) Array Size: 3840(H) x 2160(V) Holder: M12 (S-Mount) FOV: 131° (D), 113° (H), 61° (V) (with the lens provided by e-con) Electrical & Mechanical: Operating Voltage: 3.3V ±5% Operating Temperature Range: -30°C to 70°C Typical power consumption: 0.7W Size in mm (l x b): 30 x 30 mm Miscellaneous: Compliance: RoHS
