Heating thermostat Universa U 20 TE

laboratorybenchtopdigital

Product description
The Universa U 20 TE is a bath circulation thermostat with a transparent polycarbonate bath, designed for precise temperature control in laboratory and industrial process applications. The unit accepts an optional pump connection kit and a bath cover for extended functionality and external circulation.

Key features

• Bath circulation thermostat for standard temperature control tasks up to 100 °C; intuitive 3-button operation and bright VA LC two-line display.
• Reliable integrated circulation pump with flow reduction for adjustable volume flow and steady pressure.
• Modern connectivity with integrated Ethernet and USB interfaces; integrated Wi‑Fi (import/use restricted to certified countries/regions).
• Modular design with interchangeable control head and heating/cooling base for future upgrades.
• Integrated timer with countdown for time-controlled temperature processes.
• Remote control and monitoring via built-in web server, LAUDA Command app or browser; PKI and 2-factor authentication; optional connection to LAUDA.LIVE for cloud analysis and remote maintenance.
• Safety functions including low-level and overheating protection for use with non-flammable liquids, with audible and visual alarms.

Working range

• Min. working temperature: 35 °C
• Max. working temperature: 100 °C
• Temperature stability: 0.05 ± K

Technical data (according to DIN 12876)
Working temperature range: 35 ... 100 °C
Working temperature range with water cooling: 20 ... 100 °C
Operating temperature range (medium): -30 ... 100 °C
Ambient temperature range: 5 ... 40 °C
Temperature stability: 0.05 ± K
Max. power consumption: 2.4 kW
Current consumption: 10 A
Bath opening (WxD): 130 x 270 mm
Min. / max. bath volume: 13.3 / 20.0 L
Max. discharge pressure: 0.2 bar
Max. pump flow: 15 L/min
Dimensions (WxDxH): 363 x 510 x 381 mm
Weight: 18 kg
Power supply: 200-240 V, 50/60 Hz
Power plug: Power cord with angled plug (CEE7/7)

Model & technical specifications

• Model: Universa U 20 TE
• Bath material: transparent polycarbonate (suitable up to Tmax = 100 °C)
• Bath volume (min / max): 13.3 / 20.0 L
• Temperature range (set): 35 ... 100 °C (20 ... 100 °C with water cooling)
• Temperature stability: 0.05 ± K
• Pump capacity: max. 15 L/min (max. discharge pressure 0.2 bar)
• Interfaces: Ethernet, USB (standard); Wi‑Fi integrated (use/import limited to certified regions)
• Remote options: LAUDA Command, LAUDA.LIVE (cloud)
