Ultrasound imaging test phantom DP-C01

for radiographyfor tomographyfor CT scan

Short description
The Doppler Phantom DP-C01 is a partial skull phantom designed for medical imaging research, development, training and testing across X‑ray/CT, Ultrasound (US) and MRI modalities. It reproduces realistic cranial geometry with internal porosity and includes internal vessel channels that can be filled with water or blood‑mimicking fluids.

Use & compatibility
The phantom is compatible with common contrast agents and imaging media including barium sulfate, iodine‑based and gadolinium‑based agents, microbubbles and iron oxide formulations. Customization options are available to adapt the phantom to specific experimental or training protocols.

Features

• Partial skull phantom geometry
• Option to fill cranial cavity with acoustically appropriate brain‑mimicking material
• Internal blood vessel channels
• Standard tubing and connector interfaces to the vessel network
• Compact enclosure for integration and handling
• Thin protective film on phantom surface
• Embedded target wires for registration and alignment

Included in order

• Doppler Phantom (DP-C01)
• User manual and assembly instructions
• 2‑year warranty and unlimited customer support

Size & Weight
Phantom: 8 x 6 x 4 inches; Weight ≈ 1 lb.
Shipment: 12 x 10 x 10 inches; Shipment weight ≈ 6 lbs.

Materials

• Soft tissue and organs: urethane‑based soft resin
• Synthetic bones: ceramic‑reinforced epoxy composite

Technical Properties
Type of Tissue | Sound Velocity [m/s] | Density [g/cm3] | Attenuation at 2.25 MHz [dB/cm]
Cortical Bone | 3000 ± 30 | 2.31 | 6.4 ± 0.3
Trabecular Bone | 2800 ± 50 | 2.03 | 21 ± 2
Brain Matter | 1400 ± 10 | 0.99 | 1.0 ± 0.2
Skin Tissue | 1400 ± 10 | 1.02 | 1.7 ± 0.2

HU values of the tissue-mimicking materials (average)
Brain Tissue: -25
Trabecular Bone: 800
Cortical Bone: 1300

Section thicknesses
Section | Cortical Outer Thickness [mm] | Trabecular Thickness [mm] | Cortical Inner Thickness [mm] | Total Thickness [mm]
A | 1.5 ± 0.2 | 1 ± 0.2 | 1.0 ± 0.2 | 3.5 ± 0.2
B | 1.5 ± 0.2 | 2 ± 0.2 | 1.0 ± 0.2 | 4.5 ± 0.2
C | 2.5 ± 0.2 | 3 ± 0.2 | 1.0 ± 0.2 | 6.5 ± 0.2

Notes
Minor variations in appearance or measured values may occur due to material properties and standard production tolerances. The phantom can be modified to meet application‑specific requirements.

Caractéristiques / Spécifications techniques

• SKU: DP-C01
• Denomination commerciale (model): Doppler Phantom
• Marque: True Phantom Solutions
• Intended modalities: X‑Ray, CT, Ultrasound (US), MRI
• Filling options: water or blood‑mimicking fluids
• Compatible contrast mediums: Barium‑sulfate, Iodine‑based, Gadolinium‑based, Microbubble, Iron Oxide‑based
• Phantom size: 8 x 6 x 4 inches; weight ≈ 1 lb
• Shipment size: 12 x 10 x 10 inches; shipment weight ≈ 6 lbs
• Soft tissue material: urethane‑based soft resin
• Synthetic bone material: ceramic‑reinforced epoxy composite
• Acoustic examples: cortical bone sound velocity 3000 ± 30 m/s; brain matter 1400 ± 10 m/s
• Density examples: cortical bone 2.31 g/cm3; brain matter 0.99 g/cm3
• Attenuation examples at 2.25 MHz: cortical bone 6.4 ± 0.3 dB/cm; brain matter 1.0 ± 0.2 dB/cm
• HU averages: brain tissue -25; trabecular bone 800; cortical bone 1300
