Telemonitoring module EIO-SMARC-10

USBEthernet

Product introduction
EIO-SMARC-10 is a development carrier board for SMARC 2.1.1 pinout modules. It exposes the full SMARC 2.1.1 pinout and provides standard interfaces and connectors to support module development, validation and rapid prototyping. Board size: 146 × 101.6 mm. Supports Windows and Linux.

Product features

• Full SMARC 2.1.1 carrier board exposing all module signals.
• Compact dimensions (146 × 101.6 mm) for integration in varied enclosures.
• Storage expansion: 1 × M.2 Key‑M, 1 × SD3.0 slot, 1 × SATA 3.0 port.
• Video outputs: 1 × HDMI, 1 × DP, 1 × eDP/LVDS (optional) for multi-display configurations.
• Dual Gigabit Ethernet: 2 × LAN for networked applications.
• Serial connectivity: 1 × DB9 (RS232/422/485) on rear I/O plus 3 serial headers (including 2 × RS485).
• Operating ranges: 0 ~ 60°C (operating); -40 ~ 85°C (storage). Power input: 12V (ATX or DC).

Specification (table)
Model: EIO-SMARC-10
Form factor: SMARC 2.1.1 carrier board
Expansion slot (M.2): 1 × M.2 Key‑M
SD: 1 × SD3.0
Storage (SATA): 1 × SATA3.0
Graphics (rear I/O): 1 × HDMI, 1 × DP
Graphics (header): 1 × eDP/LVDS (option LVDS or eDP)
USB / Type‑C (front I/O): 2 × USB3.0, 2 × USB2.0
USB (header): 1 × USB2.0 (2.54 mm)
Ethernet (rear I/O): 2 × LAN
COM (rear I/O): 1 × DB9 (RS232/422/485)
COM (header): 1 × RS232/RS422/RS485 (2.00 mm), 2 × RS485 (2.00 mm)
GPIO (header): 1 × GPIO (2.00 mm)
Audio (front I/O): 1 × 3.5 mm jack
Audio (header): 1 × audio (2.54 mm)
Buttons/others: 1 × Power
Power type: ATX: 12V; DC: 12V
DC power input: 12V (12.5A); 12–19V (12.5–9.5A)
RTC battery: limit 3.3 V / 210 mAH
Operating temperature: 0 ~ 60°C
Storage temperature: -40 ~ 85°C
Operating humidity: 5% ~ 85% (0 ~ 45°C), non‑condensing
Storage humidity: 5% ~ 95%, non‑condensing
Dimensions: 146 × 101.6 mm
PCB color: Green
OS: Microsoft (supported), Linux (supported)

Technical specifications

• Model: EIO-SMARC-10
• Standard: SMARC 2.1.1 carrier board
• Dimensions: 146 × 101.6 mm
• Storage: M.2 Key‑M, SD3.0, SATA3.0
• Display: HDMI, DP, eDP/LVDS (option)
• USB: 2 × USB3.0, 2 × USB2.0 (front) + 1 × USB2.0 header
• Networking: 2 × LAN (Gigabit)
• Serial: DB9 (RS232/422/485) + header serials including RS485
• Audio: 3.5 mm jack + header audio
• Power: ATX/DC 12V input (12V, 12.5A; 12–19V supported)
• Operating temp: 0 ~ 60°C; Storage temp: -40 ~ 85°C
• OS support: Windows and Linux
