Hospital room door drive SW100

electromechanical

Overview
The ASSA ABLOY SW100 is a universal low-energy swing door operator engineered to automate single- and double-leaf entrances with low noise and reduced energy consumption. Its compact design and configurable modes make it suitable for healthcare, residential, office and public service environments where discreet, reliable access is required.

Applications

• Low-energy interior and exterior entrances
• Single and double leaf doors
• Fire doors (subject to national regulations)
• Escape routes
• Push and pull operation

Additional information
An optional embedded battery backup with monitoring ensures continued operation during power interruptions. The unit supports a wide range of installation configurations and can be adapted for push/pull use and fire-door applications in accordance with local codes. Refer to official technical documentation for configuration guidance.

Features

• Universal swing door operator for varied entrance types
• Low-energy operation for cost-effective automation
• Low noise during operation — suitable for sensitive environments
• Optional embedded battery backup and monitoring for operation during power outages
• Suitable for single and double leaf doors with push and pull operation

Technical specifications

• Product ID: SW100
• Power supply: 100–240 V AC, +10/-15%, 50/60 Hz
• Mains fuse (building installation): max. 10 A
• Power consumption: max. 75 W
• Auxiliary voltage: 24 V DC, max. 400 mA
• Monitored battery backup unit: 24 V DC
• Electromechanical locking connection: 12 V DC, max. 500 mA or 24 V DC, max. 250 mA
• Ambient temperature range: -20 °C to +45 °C
• Relative humidity (non-condensing): up to 95%
• Recommended maximums (see official documentation): PUSH / PULL performance and recommended door weights/widths depend on configuration
