Containment isolator AMIfor active pharmaceutical ingredientsfor highly potent active pharmaceutical ingredientsfor production
Add to favorites
Compare this product
Characteristics
- Applications
- containment, for active pharmaceutical ingredients, for highly potent active pharmaceutical ingredients, for production
- Configuration
- floor-standing, modular
- Other characteristics
- glove box, with HEPA filter, stainless steel, custom, interface, with sloped sliding window
- OEB level
- OEB 5, OEB 6
- Filtration efficiency
100 %
- External width
385 cm
(151.57 in)- External depth
78 cm
(30.71 in)- External height
95 cm
(37.4 in)- Internal width
85 cm, 130 cm
(33.46 in, 51.18 in)- Internal depth
65 cm
(25.59 in)- Internal height
85 cm
(33.46 in)- Weight
1,000 kg
(2,204.62 lb)
Description
High-containment AMI line isolators designed for the safe handling of APIs and HPAPIs in solid form at laboratory and process scale. Constructed from monolithic AISI 316L stainless steel, available with two, three or four glove ports and equipped with filtration and control systems to ensure containment and operational safety.
Main applications:
Key features:
Available options:
Characteristics / technical specifications:
Main applications:
- Handling of HPAPIs (Highly Potent APIs)
- Handling of APIs
- Laboratory procedures
- Process applications
- cGMP compliance
Key features:
- Spacious work chamber with inclined, openable front wall
- Prismatic-shaped airlock (pre-chamber)
- Pneumatic seals and safety interlocks
- Bottom discharge for liquids and solids (continuous liner)
- Passages for fluids and cables
- Overpressure valves
- HEPA H14 filtration on inlet and outlet
- Filtered outlet with Bag-IN/Bag-OUT safety system
- Filter efficiency monitoring
- HMI touch panel for managing all functional parameters of the isolator
- Audible and visual alarms
Available options:
- Oxygen analyzer (inertization)
- Fixed CIP system (spray balls)
- Manual decontamination system (spray guns)
- Continuous liner for safe solids disposal with interlocked hatch
- RTP pass-through door
Characteristics / technical specifications:
- Construction material: monolithic AISI 316L stainless steel
- Number of gloves: available with 2, 3 or 4 glove ports
- Safety systems: door interlocks, internal pressure monitoring, filter integrity monitoring, alarms
- Filtration: HEPA H14 on inlet and outlet; Bag-IN/Bag-OUT system for safe filter removal
- Discharge system: bottom discharge for liquids and solids (continuous liner)
- Control and interface: HMI touch panel for parameter and alarm management
- Customization possibilities: versions with multiple independent work chambers and custom sizing (examples: chambers 850L x 650W x 850H and 1300L x 650W x 850H; support frame e.g. 3850L x 780W x 950H; indicative weight approx. 1000 kg)
Catalogs
AMI Standard Line
2 Pages
AMI LINE - Custom projects
2 Pages
