Wall-mounted surgical light Geeta500+600

LEDfor operating rooms2-arm

Product Introduction
The Geeta500+600 dual-head wall-mounted LED surgical light combines the fixed-color Geeta500C and the adjustable-color Geeta600C to deliver uniform, shadow-free illumination for demanding operating rooms. Engineered for long-term clinical use with German Osram LEDs and ABS housings, the system supports a wide range of procedures with high color fidelity, adjustable brightness and focus, and intuitive touchscreen control.

Key Features

• Dual-head configuration: Geeta500C + Geeta600C for extended coverage and elimination of blind spots over large surgical fields.
• High-quality light source: German Osram LEDs with individual optical lenses, uniform and flicker-free, lifespan ≥60,000 hours.
• Precision control and adjustment:
  • LCD touchscreen for intuitive operation
  • Electric and button-controlled focus adjustment (18–240 mm) on each head
  • 20-step adjustable brightness per head (40,000–160,000 Lux)
• Color temperature options:
  • Geeta500C: fixed 4500K (optionally adjustable)
  • Geeta600C: 4500K–5500K, 5-step adjustment to suit surgical visual needs
• Accurate color rendering: Ra ≥97; R9/R13/R15 ≥95 for true tissue and blood color reproduction.
• Low thermal impact: Area temperature rise <0.5°C per head to protect tissues during prolonged procedures.
• Flexible positioning: Each arm provides 800 + 900 mm reach for optimal lamp placement.

Technical Specifications

• Model: Geeta500+600
• Control Type: LCD Touch Control
• Focus Adjustment: Electric & Button Control (18–240 mm)
• Lamp Head Material: ABS
• Lamp Head Thickness: ≤6.5 cm
• Lamp Head Diameter: 740 mm
• Light Source: German Osram LED, Lifespan ≥60,000 hours
• LED Count: 57 (500) + 72 (600)
• Optical Lens: Individual lens for each LED
• Brightness Range: 40,000–160,000 Lux (20 steps per head)
• Focus Range: 18–240 mm (button control, per head)
• Color Temperature: 500: fixed 4500K (optional adjustable); 600: 4500–5500K (5 steps)
• Color Rendering Index (Ra): ≥97
• Special CRI (R9/R13/R15): ≥95
• Lighting Depth (L1+L2): ≥1300 mm
• Area Temperature Rise: <0.5°C
• Power Consumption: 50W (500) + 75W (600)
• Power Input: AC100–240V 50/60Hz, switch power supply
• Arm Reach: 800 + 900 mm
• Warranty: 2 years
