Ceiling-mounted surgical light FY-5+3A

LEDfor operating rooms2-arm

Product
FY-5+3A LED surgical light — ceiling-mounted, dual head with 5-petal main and 3-petal auxiliary lamp heads. Designed for operating rooms requiring shadowless, adjustable illumination.

Overview
Focustable petal lamp heads with an independent grip on each petal. Manual focusing via central sterile handle. Cool LED light source with low heat emission (surface temperature rise ≤1℃). High color rendering (Ra 85–97). Ultra-thin ABS housing ≤10 cm supports laminar airflow. LED lifespan ≥80,000 hours.

Key Features

• Dual focustable-petal heads: 5-petal main + 3-petal auxiliary
• Independent sterile grip on every petal for precise positioning
• Optimized lamp control system for stable, flicker-free output
• Manual adjustable focus via central sterile handle (120–300 mm)
• Cool LED source, low heat emission, surface temperature rise ≤1℃
• High color rendering index Ra 85–97 for accurate tissue color
• Ultra-thin ABS lamp housing ≤10 cm for improved airflow
• Long LED service life ≥80,000 hours
• Ceiling-mounted installation suitable for operating rooms

Technical Specification

• Model: FY-5+3A
• Lamp head structure: 5-petal main head + 3-petal auxiliary head
• Shell material: ABS
• Lamp head thickness: ≤10 cm
• Lamp head diameter: 720 mm (main) / 720 mm (auxiliary)
• Horizontal arm reach: 800 + 900 + 720 mm
• LED quantity: 65 (main) / 42 (auxiliary)
• Power consumption: 65 W (main) / 42 W (auxiliary)
• Brightness: 40,000–160,000 Lux, stepless adjustable
• Focus range: 120–300 mm (manual)
• Color temperature: 3700 K–5000 K (adjustable)
• Color rendering index (Ra): 85–97
• Effective lighting depth: 500–1800 mm
• Local temperature rise: ≤1℃
• Input voltage: AC 100–240 V 50/60 Hz
• Installation type: Ceiling-mounted
• Warranty: 2 years
