Thermostatic test chamber PGC-08

climatichumiditytemperature

Description
Labotemp Plant Growth Chamber PGC-08 is a 250 L climate-controlled growth chamber engineered for reproducible plant experiments and small-scale production. Temperature control range 0–65 °C with ±0.1 °C accuracy and ±0.5% fluctuation. Interior dimensions 1000×550×450 mm with 2 adjustable stainless-steel shelves. Three-sided High-Lux lighting (15,000 LUX) with sealed-glass lamp separation for in-place lamp replacement. Adjustable airflow protects seedlings and ensures uniform conditions. Programmable LCD PID controller (timer 0–9999 min) manages temperature, humidity and illumination cycles and includes alarm and power-failure recovery. Energy-efficient R134a refrigeration with auto-defrost. Rated power 1.0 kW, 220 V input.

Designed for
Plant research, seed germination, plant tissue culture, algal reproduction, plant-derived pharmaceutical R&D, small-insect and Drosophila cultivation, and commercial horticultural R&D. Rapid, uniform lighting and tight environmental control support high repeatability for growth trials, phenotype screening and protocol development.

Why Choose Labotemp Plant Growth Chamber PGC-08?

• Optimized growth environment: 15,000 LUX three-sided lighting combined with adjustable airflow for uniform illumination and reduced edge effects.
• Compliance & durability: corrosion-resistant stainless-steel inner chamber, R134a refrigeration with auto-defrost; CE and ISO 13485 compliant.
• Laboratory-grade precision: ±0.1 °C PID temperature control, alarm and power-failure recovery for reproducible results.

Features

• High-Lux 15,000 LUX lighting system.
• Three-sided lighting (both sides + door) for uniform plant illumination.
• Sealed-glass separation allows lamp replacement without interrupting cultivation.
• Adjustable airflow control to prevent excessive drafts on seedlings.
• Stable simulation of temperature, humidity and illumination cycles.
• Programmable LCD PID controller with timer (0–9999 min) and alarm functions.
• Energy-efficient R134a refrigeration with low temperature fluctuation and auto-defrost.
• Stainless-steel inner chamber with adjustable shelves for corrosion resistance and easy cleaning.

Standard Accessories

• Programmable LCD PID controller.
• Partitions with built-in light tubes (lighted shelves).
• Power cord.

Optional Accessories

• Touchscreen controller.
• Printer.
• Illuminated partition.
• Lighting dimming control.

Applications

• Controlled plant research and experiments.
• Seed germination and plant tissue culture.
• Algal reproduction studies.
• Plant-derived pharmaceutical R&D.
• Cultivation of small insects and Drosophila.
• Commercial horticultural R&D and phenotype screening.

Technical specifications

• Temperature range: 0–65 °C
• Volume: 250 L
• Power: 1.0 kW
• Interior size (H×W×D): 1000×550×450 mm
• Voltage: 220 V
• Temperature accuracy: ±0.1 °C
• Temperature fluctuation: ±0.5 %
• Timer: 0–9999 min
• Shelves: 2 pcs (adjustable stainless-steel)
• Illumination: 15,000 LUX (three-sided High-Lux)
• Packing size (mm): 1900×930×900
• Net weight: 210 kg
• Gross weight: 230 kg
