Forced convection laboratory incubator BJPX-ST series

for scientific researchfor microbiologyfor biochemistry

Product overview
Brand: BIOBASE
Model: BJPX-ST68B / BJPX-ST80B
Product origin: CHINA
Delivery time: Within 7 days
Supply capacity: Factory direct supply

Applications
Designed for bacterial culture, fermentation, hybridization, biochemical reactions, enzyme assays and cell/tissue research. Suited for laboratories in biology, molecular science, food testing and environmental analysis.

Key features

• Smooth acceleration and rubber-cushioned feet to reduce splashing and ensure stable operation at high speed.
• Low-heat DC motor with high starting torque, wide speed range and maintenance-free operation.
• 7.0-inch touch screen with real-time display of temperature and speed; intuitive control.
• Independent temperature-limit alarm and automatic heater cut-off; shaking stops when door is opened.
• High-definition tempered glass door for observation; optional concealed water collection box (BJPX-ST80B).
• Data functions: historical data, curve and alarm query, data storage/export; Chinese/English interface; mobile remote control option.
• Uniform forced-convection heating, PID microcomputer control and precise temperature regulation.

Technical parameters
Model: BJPX-ST68B | BJPX-ST80B
Capacity: 80 L
Temperature control range: RT+5~65℃ | 4~65℃ (@25℃ for ST80B)
Temperature accuracy: ±0.1℃
Uniformity: ±1℃ (@37℃ effective working surface)
Fluctuation: ≤0.5℃ (@37℃)
Timer range: 1~999 h/min
Control mode: PID microcomputer control; ST80B supports program control (multi-section)
Display: 7.0-inch touch screen
Circulation mode: Forced convection
Shaking mode: Rotary shaking, 35–300 rpm, ±1 rpm; amplitude Φ26 mm
Max capacity examples: 100 ml×23, 250 ml×15, 500 ml×9, 1000 ml×6, 2000 ml×4
Refrigerant: / | R134a/150g (ST80B)
Defrost: / | Automatic (ST80B)
Material: Exterior carbon steel spray; interior stainless steel
Power supply: AC220V 50/60Hz (standard); 110V optional
Power consumption: 500W | 650W (ST80B)
Shaking plate: 450×410 mm, 1 pc
Internal size (W×D×H): 500×450×350 mm
External size (W×D×H): 750×570×550 mm | 720×700×580 mm (ST80B)
Net weight: 60 kg | 104 kg (ST80B)

Standard accessories

• Flask clamps: 500 ml ×3, 250 ml ×4, 100 ml ×5, 50 ml ×5
• Shaking plate ×1
• Safety door
• Concealed water collecting box (BJPX-ST80B)

Optional accessories

• Mobile phone remote-control program
• UV disinfection lamp
• Illumination lamp
• Universal spring clamp; additional shaking plates
