CO2 laboratory incubator BJPX-C series

for cell culturesfor scientific researchstainless steel

Introduction
CO2 incubators provide controlled temperature, humidity and CO2 concentration to support cell culture and reduce contamination risk. BIOBASE offers the BJPX-C series in two capacities (80 L and 160 L) with air-jacket design and UV sterilization for routine laboratory and research use.

Features

• IR infrared CO2 sensor using dual‑channel, dual‑filter technology (with calibration certificate).
• Inner chamber in 304 stainless steel with electrochemical finish and semicircular corners for easier cleaning.
• Sloped bottom for efficient drainage to prevent evaporator icing and improve temperature uniformity.
• Evaporator intake with Sanhua solenoid valve and compartmentalized operation to avoid frosting and ensure rapid, stable cooling.
• Timed segmented control program enabling preset cultivation time and temperature with automatic adjustment.
• High‑efficiency heating tubes providing uniform heating around the inner chamber.
• Electrical protections and alarms: leakage current and over‑voltage protectors; alarms for over‑temperature, under‑temperature, over‑concentration and under‑concentration of CO2.

Standard accessories

• Adjustable shelves (2 pcs)
• USB interface
• CO2 relief valve
• Water tank
• CO2 gas filter

Technical parameters
Model: BJPX-C80III | BJPX-C160III
Type: Low temperature series, air jacket
Sterilization: UV sterilization
Capacity: 80 L | 160 L
Temperature sensor: PT100
Temperature range: 10~60℃
Temperature fluctuation: ±0.3℃ (@37℃)
Temperature uniformity: ±0.5℃ (@37℃)
Temperature precision: 0.1℃
Timing range: 0~999 h or continuous
Display: 7-inch touchscreen
CO2 control: IR sensor (calibrated)
CO2 range: 0~20 vol%
CO2 uniformity: 0.2 vol%
CO2 control resolution: 0.1 vol%
Ambient conditions: ambient temp. 5~30℃ (recommended 25±2℃); ambient humidity ≤80%
Filter: CO2 gas filter
Power supply: AC220V 50Hz (standard); 110V 60Hz (optional). Wiring: plug
Power consumption: 1000W
Shelves: 2 pcs, adjustable
Standard accessories: shelves, USB interface, CO2 relief valve, water tank, CO2 gas filter
Optional accessories: water pump, three‑way connector
Internal size (W×D×H): 470×362×500 mm | 588×470×620 mm
External size (W×D×H): 689×729×1240 mm | 810×748×1330 mm
Package size (W×D×H): 820×820×1390 mm | 904×842×1467 mm
Net weight: 93 kg | 144 kg
Gross weight: 115 kg | 165 kg

Characteristics / specifications

• Models: BJPX-C80III and BJPX-C160III (BJPX-C series)
• Precise temperature control and uniform CO2 regulation via calibrated IR sensor
• 7-inch touchscreen and programmable segmented timing for reproducible protocols
• Durable inner chamber (304 stainless steel) with sloped drain for easy maintenance
• Standard and optional accessories to adapt to laboratory workflows
