Sample storage cabinet

formalinfor samplesfor laboratory samples

Description
Manufactured in stainless steel 304, this cabinet is specifically designed for safe storage and handling of formaldehyde-based products, biocides and other solvent-based substances in laboratory and autopsy environments. It features an internal perforated duct and five height-adjustable perforated shelves; the cabinet is internally ventilated. The duct connects to the extraction system (for connection to building extraction) or can be connected to the extraction filtration unit (Ref. 502120). The cabinet is levelled on the floor by 4 feet with adjustable screw jacks (25 mm) to compensate floor unevenness. A hinged door provides access to the storage. The duct connection to extraction is made via a 100 mm diameter elbow located above the cabinet.

Variants and options
Available variants: double hinged door 100 x 50 x 180 cm (W x D x H) with lock, or 2 or 3 full-height sliding doors sized W 160 x H 196.5 x D 80 cm, accommodating 2 or 3 trolleys for storage access.
Cart option: Cart Ref. 3290 for euro-norm trays 600 x 400 x 78 mm, equipped with 16 runners with 100 mm vertical spacing arranged on the short side, with blocking stop at the rear and non-blocking at the front, 4 handling handles, 4 castors (2 with brake) and load capacity 100 kg/unit. Cart dimensions: 67.8 x 40 x 180 cm. Usable dimensions: 60.5 x 40 x 160 cm (W x D x H).

Packaging
Unit packed in individual cardboard.

Characteristics / technical specifications

• Material: Stainless steel 304
• Ventilation: internally ventilated
• Internal duct: perforated
• Number of shelves: 5 perforated shelves, height-adjustable
• Extraction connection: 100 mm diameter elbow located above the cabinet (connectable to building extraction or to filtration extraction unit ref. 502120)
• Stabilization: 4 feet with adjustable screw jacks (25 mm)
• Door: hinged door (variants: double hinged door or sliding doors depending on model)
• Dimensions (single door): 50 x 50 x 180 cm (W x D x H) — approx. 210 cm total height with duct and feet
• Double door variant dimensions: 100 x 50 x 180 cm (W x D x H)
• Sliding variant dimensions (2 or 3 doors): W 160 x H 196.5 x D 80 cm
• Capacity: depending on variant, compatible with 2 or 3 trolleys
• Cart option (Ref. 3290): for euro-norm trays 600 x 400 x 78 mm, 16 runners, vertical spacing 100 mm, blocking stop on rear, 4 handles, 4 castors (2 brake), load capacity 100 kg/unit, cart dimensions 67.8 x 40 x 180 cm, usable 60.5 x 40 x 160 cm
