Laboratory centrifuge LLC-201

for hematologyclinicalfor blood banks

Product overview
Labotemp blood centrifuge LLC-201 is a floor-standing clinical centrifuge engineered for high-throughput blood component separation in hospitals, blood banks and diagnostic laboratories. The unit supports up to 4 × 1000 ml, reaches 6000 rpm and a maximum RCF of 6080 × g, enabling stable separation of serum, plasma and large-volume biological samples for transfusion and clinical workflows.

Control & safety
A microprocessor control with LCD display provides precise adjustment of RPM/RCF, time and programmable acceleration/deceleration profiles for reproducible results. Safety systems include imbalance detection with automatic shutdown, motorized lid lock with controlled opening, automatic rotor identification and lid-drop protection to ensure operator safety and sample integrity in regulated medical environments.

Why choose Labotemp LLC-201

• Designed for clinical reliability: stable motor drive and electronic control for repeatable separations.
• High-capacity processing: supports batch workflows typical of blood banks and transfusion centers.
• Comprehensive safety: motorized locks and multiple automatic protections for daily use in regulated facilities.

Features

• Corrosion-resistant stainless steel chamber
• Intelligent microprocessor control with real-time LCD parameter display
• Frequency-conversion AC motor for stable, low-maintenance operation
• High-capacity rotor configurations for bulk sample processing
• LCD displaying RPM, RCF, time, acceleration and deceleration
• Automatic rotor identification and programmable memory (10 programs)
• Motorized lid lock with controlled opening mechanism
• Active imbalance detection with automatic shutdown
• Smooth acceleration and braking with 10-step control
• Castor wheels for safe movement and installation

Applications

• High-volume blood component separation in blood banks and transfusion centers
• Batch processing of clinical samples in hospitals and diagnostic labs
• Pharmaceutical sample preparation and QC workflows requiring reproducibility
• Biotechnology workflows involving large-volume cell harvesting and separation
• Industrial lab applications requiring continuous, high-capacity centrifugation
• Standardized protocols requiring controlled acceleration, timing and repeatability

Specifications (table)
General Specifications | Value
Maximum Capacity | 4 × 1000 ml
Maximum Speed | 6000 rpm
Maximum RCF | 6080 × g
Speed Accuracy | ±10 rpm
Acceleration / Deceleration | 10 / 10 steps
Max Acceleration Time | 15 sec
Max Braking Time | 15 sec
Time Range | 1 – 99 min 59 sec adjustable
Program Memory | 10 programs
Control Parameters | RPM, RCF, Time, ACC, DEC
Display | LCD
Noise Level | ≤55 dB(A)

Electrical & Construction | Value
Voltage | AC 220V
Frequency | 50 Hz
Current | 10 A
Power | 1050 W
Automatic Rotor Identification | Yes
Motorized Lid Lock | Yes
Lid Drop Protection | Yes
Imbalance Detection | Yes
Safety Lid Lock | Yes

Packaging Information | Value
Dimensions (L × W × H) | 720 × 620 × 890 mm
Weight (without rotor) | 176 kg

Optional modules / rotor & adapter options (summary)
No. | Rotor / Adapter | Max Capacity | Max Speed | Max RCF | Tube Type
1 | Angle Rotor | 12 × 15/10/5 ml | 6000 r/min | 6080 × g | PP/PC tube
1 | Adapter | 12 × 2 ml | - | - | PP/PC tube
2 | Swing Bucket | 4 × 600 ml | 4000 r/min | 3354 × g | Square cup with wind cover
2 | Adapter | 4 × 25×5/2 ml | - | - | Vacuum blood collection tubes
2 | Adapter | 4 × 12×15/10 ml | - | - | PP/PC tube
2 | Adapter | 4 × 5×50 ml | - | - | PP/PC tube
2 | Adapter | 4 × 4×100 ml | - | - | PP/PC tube
3 | Swing Bucket | 4 × 800 ml | 4000 r/min | 3443 × g | Square cup with wind cover
3 | Adapter | 4 × 30×5/2 ml | - | - | Vacuum blood collection tubes
3 | Adapter | 4 × 16×15/10 ml | - | - | PP/PC tube
3 | Adapter | 4 × 6×50 ml | - | - | PP/PC tube
3 | Adapter | 4 × 4×100 ml | - | - | PP/PC tube
4 | Swing Bucket | 6 × 600 ml | 4000 r/min | 3400 × g | Square cup with wind cover
4 | Adapter | 6 × 25×5/2 ml | - | - | Vacuum blood collection tubes
4 | Adapter | 6 × 12×15/10 ml | - | - | PP/PC tube
4 | Adapter | 6 × 5×50 ml | - | - | PP/PC tube
4 | Adapter | 6 × 4×100 ml | - | - | PP/PC tube
5 | Swing Bucket | 4 × 1000 ml | 4000 r/min | 3578 × g | Oval cup with wind cover
5 | Adapter | 4 × 42×5/2 ml | - | - | Vacuum blood collection tubes
5 | Adapter | 4 × 23×15/10 ml | - | - | PP/PC tube
5 | Adapter | 4 × 7×50 ml | - | - | PP/PC tube
5 | Adapter | 4 × 4×100 ml | - | - | PP/PC tube

Technical specifications

• Model: LLC-201
• Maximum speed: 6000 rpm
• Maximum RCF: 6080 × g
• Maximum capacity: 4 × 1000 ml
• Speed accuracy: ±10 rpm
• Time range: 1 – 99 min 59 sec adjustable
• Program memory: 10 programs
• Control parameters: RPM, RCF, Time, ACC, DEC
• Display: LCD
• Noise level: ≤55 dB(A)
• Voltage: AC 220V, Frequency: 50 Hz, Current: 10 A, Power: 1050 W
• Safety features: Automatic rotor identification, motorized lid lock, lid drop protection, imbalance detection, safety lid lock
• Construction: Stainless steel chamber, corrosion-resistant design
• Mobility: Castor wheels
