Veterinary centrifuge LLC-107

for hematologyclinicalfor blood banks

Product overview
The LLC-107 low-speed benchtop centrifuge is designed for efficient separation of biological fluids in clinical laboratories, hospitals, blood banks and research facilities. Rated up to 6000 rpm with a maximum RCF of 6080 × g, the unit accepts a 4×750 ml rotor for medium-to-high sample throughput. The reinforced metal housing and 304 stainless steel chamber provide chemical resistance and easy cleaning for routine laboratory use.

Control, safety & interface
Microprocessor control with a 7-inch LCD displays RPM and RCF, supports programmable runs and allows adjustable acceleration/deceleration (1–10 levels). Safety features include automatic lid locking, imbalance detection with automatic shutdown, safety interlock, controlled lid opening and emergency lid release. The centrifuge meets CE safety requirements for clinical applications.

Key benefits

• High-volume handling: 4×750 ml rotor for increased throughput in clinical workflows.
• Accurate speed and RCF control: stable operation up to 6000 rpm with automatic RPM/RCF conversion.
• Secure operation: automatic lid lock, imbalance protection and safety interlocks for reliable sample processing.

Features

• 7-inch LCD interface with simultaneous parameter display
• Intelligent microprocessor control with real-time parameter modification
• Frequency-conversion AC motor for stable, low-maintenance operation
• High-strength steel body with powder-coated finish
• 304 stainless steel chamber resistant to chemicals and easy to clean
• Compatibility with aluminum alloy angle rotors and stainless steel swing-out rotors
• Autoclavable rotors and buckets for contamination control
• Corrosion-resistant internal components for long service life
• Precision rotor design for smooth tube insertion and removal
• Automatic RPM/RCF conversion and up to 30 programmable memory settings
• Last-run parameter recall for repeated protocols
• Adjustable acceleration/deceleration (1–10 levels)
• Viewing port, controlled lid opening and emergency lid release
• Active imbalance detection with automatic shutdown; noise level ≤58 dB(A)

Applications

• Routine separation of blood, serum and plasma in clinical laboratories
• Sample processing in hospitals, blood banks and diagnostic centers
• PRP preparation and cellular component separation for downstream analysis
• Pharmaceutical QC and sample preparation
• Research and academic labs handling medium-volume samples
• Food and environmental testing for liquid sample clarification
• Veterinary laboratory sample processing

Specifications
General specifications
Maximum capacity: 4 × 750 ml
Maximum speed: 6000 rpm
Maximum RCF: 6080 × g
Speed accuracy: ±10 rpm
Control system: Microprocessor control
Display: 7-inch LCD
Timer range: 0 – 99 min 59 sec adjustable
Acceleration / deceleration: 1 – 10 levels
Noise level: ≤58 dB(A)

Electrical & construction
Voltage: AC 220 V
Frequency: 50 Hz
Current: 10 A
Power: 770 W
Motor type: Frequency-conversion AC motor
Dimensions (L × W × H): 600 × 470 × 370 mm
Weight (without rotor): 50 kg

Packaging information
Gross weight: 90 kg
Package size: 730 × 590 × 560 mm

Optional modules / rotors (selection)

• No.1 — Angle rotor with adapter: max 12 × 5/10/15 ml; adapter 12 × 2 ml; max speed 6000 rpm; max RCF 6080 × g; tube type: PP/PC.
• No.2 — Swing rotor with frame & adapter: max 4 × 100 ml or 4 × 50 ml; adapter 4 × 15/10 ml; max speed 5000 rpm; max RCF 4752 × g; tube type: PP/PC.
• No.3 — Swing rotor with frame & adapter: max 4 × 2 × 100 ml or 4 × 2 × 50 ml; adapter 4 × 2 × 15/10 ml; max speed 4000 rpm; max RCF 3041 × g; tube type: PP/PC/vacuum blood tubes.
• No.4 — Swing bucket: max 72 × 2–5 ml; max speed 4000 rpm; max RCF 2773 × g; tube type: vacuum blood collection tubes.
• No.5 — Swing bucket with adapter: max 4 × 250 ml; multiple adapter configurations; max speed 4000 rpm; max RCF 3354 × g; tube type: PP/PC.
• No.6 — Swing bucket with adapter: max 4 × 500 ml; multiple configurations; max speed 4000 rpm; max RCF 3354 × g; tube type: PP/PC.
• No.7 — Swing bucket with adapter: max 4 × 750 ml; multiple configurations; max speed 4000 rpm; max RCF 3443 × g; tube type: PP/PC.
• No.8 — Microplate rotor with adapter: max 2 × 2 × 96 wells; adapter 2 × 32 × 1.5 ml; max speed 4200 rpm; max RCF 3057 × g; tube type: PP/PC.
• No.9 — Swing rotor: max 6 × 2 × 30 ml; max speed 4500 rpm; max RCF 3170 × g; tube type: specialized tubes.
