Medical AI platform PCECG-500

for hospitalsfor cardiologyconverter

Product features

• Designed for hospitals, clinics, physical examination centers, community health centers and pet/veterinary centers.
• AI validated against authoritative databases (CSE, AHA, MIT-BIH, CTS) with reliable automatic measurement and analysis.
• Multiple practical, user-definable ECG diagnostic dictionaries and analysis modules.
• Quick search function for configurable search terms to facilitate patient data recording and statistics.
• Multi-format printout options: 12*1, 6*2+1, 4*3+1 on A4 paper (vertical or horizontal).
• Diagnostic report printing and integration capability with hospital information systems (HIS).
• Includes core work modules: Test Center, Task Center, Case Center, Personal Center.
• Efficient measurement tools and a customizable terminology library to support rapid clinical decision-making.
• Improved detection of abnormal events; comprehensive diagnostic accuracy reported at 95.2%.
• AI deep-learning analysis time: less than 1 minute.
• Supports classification of 98 abnormal ECG event types (including 26 arrhythmia types and 22 myocardial infarction diagnostic types).

Installation environment / PC Hardware Configuration
Name: ECG Analysis Computer
Recommended configuration: CPU: Intel® Core™ i5
RAM: 16 GB
HDD: 500 GB or larger
Display resolution: 1280×768
Printer resolution: 600 dpi

Modularized Design (The Relationship Between Four Systems And Modules)
Name of system: ECG Receiver | ECG Manager | ECG Vet Manager & Acquirer | ECG Manager & Acquirer
Type: PCECG-500(R) | PCECG-500(M) | PCECG-500(VM) | PCECG-500(A)
Brief introduction to functions: Receiver: receive ECG files from multiple devices and support format conversion, storage and output. Manager: receive and manage ECG files (register, edit, waveform review, analysis and measurement). Vet Manager & Acquirer / Manager & Acquirer: include receiver and manager functions and support real-time lead acquisition, display and analysis.
Module composition: file receiver module; human data management module; veterinary data management module; acquirer module.
Connected device: ECG (human/vet) | ECG (human) | ECG (vet) & collecting box | ECG (human) & collecting box
Standard configuration: software CD, RS232 cable, dongle (R/M/VM/A); USB cable included for VM/A variants.
Options: network converter (optional).

Ordering Information
Catalogue No.: PCECG-500

Technical specifications

• Product name: AI-ECG platform
• Brand: LEPU Medical
• Model / variants: PCECG-500 (PCECG-500(R), PCECG-500(M), PCECG-500(VM), PCECG-500(A))
• Recommended PC hardware: Intel® Core™ i5; 16 GB RAM; HDD ≥ 500 GB; display 1280×768; printer 600 dpi
• AI validation databases: CSE, AHA, MIT-BIH, CTS
• Reported comprehensive diagnostic accuracy: 95.2%
• AI analysis time: < 1 minute
• Supported diagnostic classifications: 98 abnormal ECG event types (including 26 arrhythmia types and 22 myocardial infarction types)
• Work modules: Test Center, Task Center, Case Center, Personal Center
• Print formats: 12*1, 6*2+1, 4*3+1 on A4 (vertical/horizontal)
• Integration: supports HIS connectivity and diagnostic report printing
• Standard accessories: software CD, RS232 cable, dongle; USB cable for specified variants; optional network converter
