Automated biochemistry analyzer BK-200

benchtopphotometricfor biological samples

Introduction
Used for quantitative analysis of clinical chemistry in human serum, plasma, urine, cerebrospinal fluid and other biological samples. For diagnostic laboratory use only.

Key features

• 37 sample positions
• 28 reagent positions
• 48 reusable reaction cuvettes (6 mm optical length)
• Throughput: 200 tests/hour
• Probe with Teflon coating, anti-collision and liquid-level detection
• Automatic internal and external probe washing; automatic cuvette washing
• Refrigerated reagent tray with independent switch; STAT function for priority samples

Technical parameters (summary)
Model: BK-200
Throughput: 200 tests/hour
Analysis methods: End-point, Fixed-time, Rate (kinetic), Turbidimetry
Certificates: CE, FDA, ISO9001, ISO13485

Sample & reagent system

• Sample positions: 37
• Reagent positions: 28
• Sample volume: 2–70 µl
• Reagent volume: 20–350 µl
• Probe: Teflon coating with anti-collision and liquid-level detection
• Probe washing: automatic interior and exterior
• Reagent cooling: refrigerated tray with independent switch

Reaction system

• Temperature control: 37 ± 0.2 °C
• Reaction cuvettes: 48 reusable, optical length 6 mm
• Mixer probe: independent stirring
• Cuvette washing: automatic
• STAT function: available

Optical system

• Light source: 6V/10W halogen lamp
• Spectrophotometry: post-spectral
• Wavelength range: 340–800 nm
• Absorbance range: 0–3.0 Abs

Calibration & quality control

• Calibration: linear (K factor, 1/2/multi-point), non-linear (spline, polygon, Logit-4P/5P)
• QC: real-time QC, Westgard multi-rules, cumulative sum check, twin plot (2D), daily & monthly QC

Data management

• Software: Windows 7/8/10 (32/64 bit)
• LIS: bidirectional, HL7 protocol support
• Interface: LAN port; external printer optional; multiple report modes

Working conditions

• Power supply: AC220V ±10% 50/60Hz or 110V ±10% 60Hz, 300W
• Operating temperature: 15–30 °C
• Humidity: 40%–85%
• Water consumption: deionized water < 5 L/h

Size & weight

• External dimensions (W×D×H): 625 × 425 × 460 mm
• Net weight: 36 kg
• Package size (W×D×H): 750 × 560 × 900 mm
• Gross weight: 55 kg

Certificates & compliance
CE, FDA, ISO9001, ISO13485

Commercial information

• Brand: BIOBASE
• Origin: China
• Model: BK-200
• Lead time: within 7 days
• Supply capacity: direct factory supply

Technical specifications

• Model: BK-200
• Brand: BIOBASE
• Throughput: 200 tests/hour
• Sample positions: 37
• Reagent positions: 28
• Reaction cuvettes: 48 reusable (6 mm optical length)
• Sample volume range: 2–70 µl
• Reagent volume range: 20–350 µl
• Reaction temperature control: 37 ± 0.2 °C
• Wavelength range: 340–800 nm; Absorbance: 0–3.0 Abs
• Software: Windows 7/8/10 (32/64 bit); LIS HL7 support
• Certifications: CE, FDA, ISO9001, ISO13485
