IV pole on casters I-LOW005

8-hookstainless steelheight-adjustable

Overview
The Low Gravity IV stand is designed for intensive care units and general wards, providing a flexible, mobile infusion pole with an extensive accessory program for clinical use.

Product highlights

• Softdrop system for controlled lowering of the inner tube
• 8 bottle hooks arranged in line

Advantages

• Secure suspension of infusion bottles and bags for reliable infusion management
• Mobile design with five twin castors for easy manoeuvring and electrical conductivity

Technology

• All plastic parts are lightfast
• Stainless steel tubes according to DIN EN 10217-7
• Materials ultrasonic and eddy-current tested (EN 10246-9/3)
• Integrated pull-out limiter prevents tube separation during adjustment
• Safety bottle cross according to DIN ISO 15375
• Glass-fibre reinforced plastic base for increased corrosion resistance

Safety

• Base legs sealed with plastic plugs to eliminate risk of injury
• Built-in safety distance reduces pinch risk when extending/retracting the pole
• Softdrop system controls lowering of the inner tube for safe operation
• Rounded bottle hooks minimize risk of injury
• Hook geometry prevents infusion bottles from slipping out

Application

• Outer tube provides space to attach monitoring or therapy devices at an ergonomic height

Product details
Field of application: Intensive Care
Material: Stainless steel / Plastic
Colour of plastic parts: Blue / Black
Number of hooks: 8
Arrangement of the hooks: In line with each other
Type of height adjustment: Stainless steel screw height adjustment
Maximum length/height: 2,260 mm
Minimum length/height: 1,405 mm
Inner tube diameter: Ø 25 mm
Outer tube diameter: Ø 33.7 mm
Length of outer tube: 1,200 mm
Base leg profile: Ø 33.7 mm
Base weight: Weighted
Base diameter: Ø 680 mm
Castors: Twin castors
Castor diameter: Ø 75 mm
Number of castors: 5 with brakes and electrical conductivity
Total load capacity (kg): 13
Load capacity per system (kg): 8
Load capacity per hook (kg): 2

Packaging dimensions
Packaging unit: Unit
Width Box1: 0.21 m
Height Box1: 0.13 m
Length Box1: 1.46 m
Weight Box1: 12.50 kg

Technical specifications

• Softdrop safety lowering system
• Stainless steel construction (tubes DIN EN 10217-7)
• Plastic parts lightfast
• Integrated pull-out limiter on adjustable tubes
• Safety bottle cross according to DIN ISO 15375
• Glass-fibre reinforced plastic base for increased corrosion resistance
• 8 bottle hooks arranged in line
• Height range: 1,405 mm – 2,260 mm
• Base diameter Ø 680 mm; weighted base
• 5 twin castors (Ø 75 mm) with brakes and electrical conductivity
• Total load capacity 13 kg; load capacity per hook 2 kg
