Analytical laboratory balance ACJ 100-4M

for pharmaciesfor the pharmaceutical industryfor chemical industry

Product overview
Compact analytical balance ACJ 100-4M with Single-Cell weighing technology, designed for laboratory and quality-control environments; optional conformity assessment available.

Key features

• Automatic internal adjustment on temperature change ≥ 2 °C or time-controlled every 4 h for stable accuracy independent of installation site
• Dosage aid with high-stability mode and selectable filter settings
• Recipe/mixture weighing with combined tare/print function; components auto-numbered and printed with nominal weight
• Automatic data output to PC/printer whenever the balance is steady
• 4-digit identification number, freely programmable and printed on calibration protocol
• Protective working cover included

Applications

• Pharmacies
• Food analysis
• Environmental analysis
• Chemical industry
• Research & development laboratories

Technical data (summary)
Weighing capacity [Max]: 120 g
Weighing capacity [Max] (ct): 600 ct
Readability [d]: 0.0001 g
Readability carat [d] (ct): 0.001 ct
Verification scale interval [e]: 0.001 g
Units: g, mg, ct
Conformity assessment possible ex works: yes
Minimum weight [Min]: 0.01 g
Linearity: ± 0.0003 g
Reproducibility: 0.0002 g
Stabilization time: 3 s
Tolerance weighing: yes (visual signal)
Interfaces: RS-232 standard, USB-Device
Adjustment options: Internal calibration (automatic), adjusting with internal weight (manual)
Recommended adjusting weight: 100 g (E2)
Ambient temperature: 10 °C – 30 °C
Dimensions weighing surface (Ø): 91 mm
Material draught shield: glass
Material housing: cast aluminium, plastic
Dimension housing (W×D×H): 213×333×338 mm
Material weighing plate: stainless steel
Net weight approx.: 7 kg
GTIN/EAN: 4045761235649

Technical specifications

• Weighing principle: single cell technology (single-range balance)
• Capacity: 120 g; readout 0.0001 g (0.1 mg)
• Verification scale interval (e): 0.001 g
• Units available: g, mg, ct
• Minimum weight (USP guidance): 0.01 g
• Linearity: ± 0.0003 g; Reproducibility: 0.0002 g
• Stabilization time: 3 s
• Interfaces: RS-232 and USB (Device)
• Internal automatic calibration; manual internal-weight adjustment possible (recommended 100 g, E2)
• Weighing pan Ø: 91 mm; pan material: stainless steel
• Housing: cast aluminium and plastic; draught shield: glass
• Housing dimensions (W×D×H): 213×333×338 mm; net weight ≈ 7 kg
• GTIN/EAN: 4045761235649
