Class II microbiological safety cabinet Mini
for life sciences applicationslaboratoryfor hospitals

Class II microbiological safety cabinet - Mini - Skan - for life sciences applications / laboratory / for hospitals
Class II microbiological safety cabinet - Mini - Skan - for life sciences applications / laboratory / for hospitals
Add to favorites
Compare this product

Characteristics

Class
class II
Applications
for life sciences applications, laboratory, for hospitals, for liquid handling
ISO class
ISO class 5
Configuration
benchtop
Certifications
EN 12469
Lighting
with LED light
Other characteristics
laminar flow, recirculating, with HEPA filter
External width

854 mm, 1,221 mm
(33.62 in, 48.07 in)

External depth

650 mm, 661 mm, 753 mm
(25.59 in, 26.02 in, 29.65 in)

External height

1,200 mm, 1,218 mm, 1,431 mm, 1,446 mm, 1,471 mm, 1,686 mm, 1,711 mm
(47.24 in, 47.95 in, 56.34 in, 56.93 in, 57.91 in, 66.38 in, 67.36 in)

Internal width

814 mm, 1,160 mm
(32.05 in, 45.67 in)

Internal depth

418 mm, 540 mm, 660 mm
(16.46 in, 21.26 in, 25.98 in)

Internal height

686 mm, 939 mm
(27.01 in, 36.97 in)

Description

Overview
The Mini biological safety cabinet provides comprehensive protection for liquid handling and robotics processes with dual HEPA filtration. Its space-saving, compact design fits easily into existing laboratory set-ups (depth >650 mm). Equipment can be inserted through a large, lockable front opening. Integrated alarm functions and an intuitive touchscreen control enable monitoring and safe operation.

Applications
  • Biotech & Life Sciences
  • Laboratory & Research
  • Hospital & Pharmacy

At a glance
Standard: DIN EN 12469
Filter type: HEPA 14
ISO-class: ISO 5

Characteristics
  • Compact design — minimal footprint for seamless integration into laboratories with limited space
  • Energy-efficient operation — modern fans and LED lighting reduce energy consumption and operating costs
  • Low noise performance — quiet operation improves working conditions
  • Flexible front opening — large, lockable front opening for easy access and sample protection
  • Integrated alarm functions — acoustic and visual signals alert on deviations
  • Intuitive control — touchscreen interface for clear operation and monitoring of key parameters

Requirements
  • Optimized for liquid handling — ideal for basic liquid handling and robotics processes; standardized interfaces and a stable working area for precise pipetting and reproducible results
  • Compact footprint — easy integration into laboratories with limited space without compromising functionality or safety
  • Fast installation — standard connections and modular structure for rapid integration

Functional principle
Class II workbenches with two HEPA filters: part of the filtered downflow is blown downwards as a laminar 'air stamp' to ensure product protection. This airflow is fed back to the filter or air recirculation system through table segment slots, protecting people and the environment. Part of the exhaust air is returned to the laboratory environment via the exhaust air filter free of particles and microorganisms, minimising the risk of particles from inside the workbench entering the laboratory environment.

Specifications / technical data
  • General: 2 filter levels (exhaust air, downflow) for standard versions; some variants with 3 filter levels (2 x exhaust air, downflow)
  • Standard: DIN EN 12469
  • Filter type: HEPA 14
  • ISO class: ISO 5
  • MR085G — Outer dimensions (W x D x H) in mm: 854 x 650 x 1218
    Inside dimensions, working space (W x D x H) in mm: 814 x 418 x 686
  • MR120H — Outer dimensions (W x D x H) in mm: 1221 x 661 x 1200
    Inside dimensions, working space (W x D x H) in mm: 1160 x 540 x 686
  • MU120H — Outer dimensions (W x D x H) in mm: 1221 x 753 x 1471
    Inside dimensions, working space (W x D x H) in mm: 1160 x 660 x 939
  • MD085G — Outer dimensions (W x D x H) in mm: 854 x 650 x 1431
    Inside dimensions, working space (W x D x H) in mm: 814 x 418 x 686
    Note: MD085G version with exhaust air connection
  • MD120H — Outer dimensions (W x D x H) in mm: 1221 x 661 x 1446
    Inside dimensions, working space (W x D x H) in mm: 1160 x 540 x 686
    Note: MD120H version with exhaust air connection
  • MT120H — Outer dimensions (W x D x H) in mm: 1221 x 753 x 1711
    Inside dimensions, working space (W x D x H) in mm: 1160 x 660 x 939
  • ME085J — Outer dimensions (W x D x H) in mm: 854 x 650 x 1431
    Inside dimensions, working space (W x D x H) in mm: 814 x 418 x 686
    Note: 3 filter levels (2 x exhaust air, downflow)
  • ME120K — Outer dimensions (W x D x H) in mm: 1221 x 661 x 1446
    Inside dimensions, working space (W x D x H) in mm: 1160 x 540 x 686
    Note: 3 filter levels (2 x exhaust air, downflow)
  • MX120K — Outer dimensions (W x D x H) in mm: 1221 x 753 x 1686
    Inside dimensions, working space (W x D x H) in mm: 1160 x 660 x 939
    Note: 3 filter levels (2 x exhaust air, downflow)
