Surgical display LX1910

1280 x 102419"LED-backlit

Overview
1 megapixel 19" surgical monitor for accurate grayscale imaging and clinical review.

Key Selling Points

• Supports multiple input signal resolutions
• Connects analog and digital video sources
• Factory-calibrated to DICOM Part 14

Product Features

• Clear visibility: IPS-like panel offers high contrast and wide viewing angles; flicker-free images at low refresh rates to reduce eye strain.
• Adaptable resolution handling: Displays inputs at native size, enlarged or fullscreen per user needs.
• Digital and analog inputs: DisplayPort and DVI‑I inputs (digital and analog RGBHV); automatic recognition of analog signals; adapters included for legacy systems.
• DICOM Part 14 calibration: Factory-measured grayscale tones and five default presets meeting diagnostic display specifications.
• Stable brightness and instant image display: Internal backlight sensor stabilizes brightness at startup and compensates for temperature and ageing.
• VESA mounting: Compatible with standard VESA mounts (ceiling, wall, stands).
• Accessible controls: Front OSD buttons, lockable to prevent accidental changes when mounted side-by-side.
• Ergonomic positioning: Stand version offers tilt, swivel and wide height adjustment.

Downloads & Documentation
Datasheet, product brochure and instructions for use available from the manufacturer's download resources.

Technical specifications

• Models: LX1910 (without stand); LX1910-S (with stand, black)
• Certifications: CE/UKCA (Medical Device), IEC/EN60601-1, CAN/CSA C22.2 No. 60601-1, ANSI/AAMI ES60601-1, EN60601-1-2 Class B, FCC-B, RoHS, China RoHS, WEEE, CCC, BIS
• Accessories: D-Sub–DVI adapter, BNC–D-Sub adapter, Utility Disk (PDF instructions); may vary by country
• Panel: IPS-like; Backlight: LED; Screen size: 19" (48.3 cm); Native resolution: 1280 x 1024 (5:4)
• Viewable image (H x V): 376.3 x 301.1 mm; Pixel pitch: 0.294 x 0.294 mm; Display colors: 8-bit
• Viewing angles: 178°/178°; Brightness (typical): 700 cd/m²; Recommended calibration brightness: 400 cd/m²; Contrast ratio: 1000:1
• Response time: 13 ms rising, 12 ms falling; Inputs: DisplayPort, DVI‑I (digital and analog RGBHV)
• Scanning frequency (digital/analog H/V): 30–100 kHz / 50–85 Hz; Sync formats: Separate, Composite, SoG
• USB: Upstream USB 2.0 Type‑B; Downstream USB 2.0 Type‑A
• Power: AC 100–240 V, 50/60 Hz; Max consumption: <45 W; Power save: <2 W; Power output: DC 5V, 1A (Hirose)
• Misc: Priority input (DVI‑A) for emergency signal; Backlight sensor; OSD languages: English, German; IP rating: IP20
• Physical: Net weight LX1910: 4.3 kg; LX1910‑S: 6.1 kg; VESA: 100 x 100 mm, M4, depth 5–10 mm
