Vaccine freezer ULF-13

for hospitalsfor blood plasmalaboratory

Overview
Labotemp Ultra Low Temperature Freezer ULF-13 is a vertical ultra-low temperature (ULT) freezer designed for controlled storage at −86°C. The 308 L capacity upright freezer uses a SECOP compressor, condensing fan and microprocessor electronic control with a digital display to maintain stable temperatures. The interior is 304 stainless steel and the exterior is galvanized sheet with a powder-sprayed finish. The unit includes a lockable door, rigid unibody structure and multi-level audible/visual alarms for temperature and door-ajar events, with an ambient operating range of 16–32°C. Suitable for laboratories, hospitals and research institutes for preserving vaccines, enzymes, plasma and sensitive biosamples.

Key selling points

• Microprocessor temperature control with setpoint down to −86°C.
• 308 L vertical design for organized sample storage.
• SECOP compressor with condensing fan for reliable cooling.
• 304 stainless-steel inner chamber and galvanized, powder-sprayed exterior for hygiene and durability.
• Digital display, electronic thermostat and multi-level audible/visual alarms (high/low temperature, door ajar); lockable door for secure access.
• Designed to operate in 16–32°C ambient conditions; 580 W input power.

Features (as listed)

• Energy-efficient operation
• 308 L vertical freezer adjustable down to −86°C
• SECOP compressor and Chinese-brand condensing fan
• Air cooling system with microprocessor electronic control and digital display
• 304 stainless-steel inner chamber; galvanized, powder-sprayed exterior
• Audible and visual alarms for high/low temperature and door ajar
• Lockable door; input power 580 W; ambient operation 16–32°C

Applications

• Storage of biological samples, vaccines, enzymes, plasma and reagents in laboratories, research institutes and hospitals under ultra-low temperature conditions.

Specifications (table)
Model : ULF-13
Capacity : 308 L
Temperature range : −86°C, adjustable
Compressor : SECOP
Voltage : 220V 50Hz
Input power : 580 W
Condensing fan : Chinese brand fan
Cooling type : Air cooling
Thermostat : Electronic
Display : Digital display
Exterior size : 890 × 760 × 1810 mm
Interior size : 570 × 485 × 1140 mm
Exterior material : Galvanized sheet, powder-sprayed
Interior material : 304 stainless steel
Lock key : Yes
Control system : Microprocessor control
Ambient temperature : 16–32°C
Environmental humidity : 20–80%
Alarm : Audible and visual alarm for high/low temperature and door ajar
Package size : 950 × 980 × 1885 mm
Net weight : 160 kg
Gross weight : 195 kg

Technical specifications

• Model: ULF-13
• Volume/Capacity: 308 L
• Temperature range: down to −86°C (adjustable)
• Compressor: SECOP
• Cooling type: Air cooling with condensing fan
• Control: Microprocessor electronic control with digital display
• Power: 580 W input power; Voltage 220V 50Hz
• Interior material: 304 stainless steel
• Exterior material: Galvanized sheet, powder-sprayed
• Exterior dimensions: 890 × 760 × 1810 mm
• Interior dimensions: 570 × 485 × 1140 mm
• Package size: 950 × 980 × 1885 mm
• Net weight: 160 kg; Gross weight: 195 kg
• Ambient operating range: 16–32°C; Environmental humidity: 20–80%
• Security & alarms: Lockable door; audible and visual alarms for high/low temperature and door ajar
