Pharmacy freezer ULF-01A

for vaccineshospitalfor blood plasma

Product Overview
Labotemp -86°C Ultra Low Temperature Freezer ULF-01A is a compact and reliable ultra low temperature chest freezer designed for secure storage of sensitive biological and clinical samples. Maintaining a stable operating temperature of -86°C, this ULT freezer is suitable for preservation of vaccines, plasma, enzymes, DNA samples and research materials in laboratories, hospitals and research facilities. The 25 L 304 stainless steel interior provides corrosion resistance and easy sanitization, while 90 mm insulation reduces thermal loss and improves temperature stability during continuous operation.

Performance and Design
Engineered for consistent performance, the ULF-01A integrates a SECOP compressor with a single-stage refrigeration system for efficient cooling. Digital temperature control with a PTC sensor enables precise monitoring, and an EBM condenser fan ensures effective heat dissipation. The unit features audible and visual alarms plus multiple protection functions to enhance operational safety and protect stored samples. Its compact chest design delivers space-efficient installation and low-noise operation appropriate for laboratory environments.

Key Features

• 25 L compact storage capacity
• Stable -86°C ultra-low temperature regulation
• Digital temperature control with PTC sensor for precise monitoring
• SECOP compressor with single-stage refrigeration for energy-efficient operation
• Wi-Fi enabled temperature recorder with alarm and long-term data logging (up to 1 year)
• 90 mm thick insulation for minimal thermal loss and improved stability
• CFC-free refrigerant for environmentally responsible operation
• 304 stainless steel interior chamber for corrosion resistance and easy sanitization
• Low noise operation (55 dB(A)) suitable for lab environments
• Compact chest design for space-efficient installation
• EBM fan-assisted condenser for efficient heat dissipation
• Integrated audible and visual alarm monitoring system for sample protection

Applications

• Ultra-low storage (-40°C to -86°C) for enzymes, reagents and biological samples
• Temperature-sensitive sample preservation with digital monitoring and alarm systems
• Laboratory and clinical storage requiring stable thermal control and data logging
• Pharmaceutical QA storage with traceable temperature records (Wi‑Fi enabled)
• Research applications requiring contamination-resistant stainless steel chambers

Standard Accessories

• Wi‑Fi enabled temperature recorder with alarm and long-term data logging capability

Technical Specifications

• Capacity: 25 L
• Temperature Range: -86°C
• Power Supply: 110 V / 60 Hz
• Rated Input Power: 230 W
• Power Consumption: 3.8 kWh / 24 h
• Temperature Control: Digital controller
• Temperature Sensor: PTC
• Compressor: SECOP
• Refrigeration System: Single-stage
• Refrigerant: CFC-free
• Interior Material: 304 stainless steel
• Exterior Material: PVC
• Insulation Thickness: 90 mm
• Noise Level: 55 dB(A)
• Net / Gross Weight: 29 kg / 45 kg
• Internal Dimensions (W×D×H): 325 × 220 × 355 mm
• External Dimensions (W×D×H): 780 × 410 × 515 mm
• Packing Dimensions (W×D×H): 810 × 430 × 535 mm
