Arm curl gym station R8303

Description
The R8303 Unilateral Biceps Curl is engineered for precise, balanced arm training. Independent iso‑lateral movement allows each arm to work separately, promoting symmetrical muscle development and controlled contraction throughout the range of motion. Biomechanical design and self‑aligning grips replicate a natural curl path for smooth, comfortable execution.

Usage level
Intensive use — suitable for professional gym environments

Technical features

• Frame: cold‑rolled Q235A steel for high structural strength.
• Main sections: square tubes 40 × 140 mm and oval tubes 50 × 100 mm.
• Iso‑lateral independent arms enabling individual and balanced work.
• Cable transmission system engineered for continuous operation.
• Magnetic selector pin for quick and secure weight selection.
• Shrouded weight tower protecting the plates and limiting access to moving parts.
• Cast‑iron weight plates with textured black powder coating and Teflon rings for smooth travel.
• Option to add two micro‑weights of 2.5 kg each for finer load increments.
• Seat and support pads in high‑density PU with antibacterial upholstery for frequent use.
• Pneumatic seat height adjustment with up to 15 positions.
• Backrest inclinable in 5 positions to ensure optimal elbow alignment.
• Self‑aligning ergonomic grips.
• Rubberized non‑slip grips with aluminium collar at the ends.
• Individual arm support pads positioned to optimise movement and muscle activation.
• Exercise pictogram indicating correct execution and targeted muscle area.
• Base with PVC feet to protect flooring and improve stability.

Dimensions and weight

• Length: 150 cm
• Width: 132.5 cm
• Height: 160.2 cm
• Weight: 219 kg
• Maximum plate weight: 80 kg

Technical specifications

• Frame material: cold‑rolled Q235A steel.
• Main sections: square 40 × 140 mm and oval 50 × 100 mm tubes.
• Load system: shrouded weight tower with magnetic selector pin; cast‑iron plates with powder coating and Teflon rings.
• Adjustments: pneumatic seat (up to 15 positions); backrest adjustable in 5 positions.
• Accessories/options: two 2.5 kg micro‑weights available; self‑aligning, rubberized grips with aluminium collar.
• Recommended use: intensive environments (professional gyms).
