Automatic glassware washer GWF29-SC-00G

for the food industryfor the pharmaceutical industrylaboratory

Overview
Smeg-designed in Italy glassware washer for laboratory, pharmaceutical and agro-food applications. Modular loading and optimized chamber geometry provide high flexibility for mixed and dedicated loads, while high-temperature washing and boosted forced hot-air drying deliver fast, residue-free results.

Modularity
Interchangeable modules allow configuration according to glassware shape and size (bottles, flasks, pipettes, vials). Modules can be positioned left or right on each trolley and on both loading levels to maximize usable space with mixed loads.

Optimized capacity
The chamber layout supports simultaneous washing of items with varied dimensions; 1000 ml bottles can be processed on both loading levels at the same time, improving throughput for batch workflows.

Repositionable upper rack
Two identical loading levels with an upper rack configurable at two heights enable multiple loading schemes without additional trolleys or accessories, facilitating quick changeovers between product types.

High-performance washing and drying
Designed washing circuits and a forced hot-air drying system with a 50% boost shorten cycle times and reduce residual moisture, delivering glassware ready for reuse faster.

Programs and control
Electronic control with display alarms, remaining-time and end-of-cycle indicators. Traceability of the last 300 executed programs with cycle archive. 20 standard programs and 20 modifiable programs; program editing available. Cycle download optional via LAN or USB.

Optional accessories

• CFL-S
• CFL-I
• MFL-8P
• MFL-20P
• MFL-35P
• MFL-LBT3
• MFL-PT100
• MFL-PT20L
• MFL-C4B4
• MFL-C8
• MFL-IRS

Technical specifications

• Type: Glassware washer 90 cm
• Model code: GWF29-SC-00G
• Working temperature: Up to 95 °C
• Washing levels: up to 2
• Upper level reconfigurable at two different heights: Yes
• Enhanced forced hot-air drying system: Yes (50% boost)
• HEPA Filter: Optional
• Door: Stainless steel door with glass porthole
• Washer Chamber Material: AISI 316L
• External material of the machine: AISI 304
• Chamber capacity (net volume): 152 l
• Chamber with rails: Yes
• Modular system for high loading flexibility: Yes
• Undercounter installation: Yes
• Electrical connection: 3N AC 400V - 50Hz
• Monophase conversion: Yes, using ad hoc optional kit (WD-EC4290-1)
• Convertible in tri-phase without neutral: Yes, using ad hoc optional kit (WD-EC4290-3)
• 60 Hz possibility: Yes, on demand
• Plug: Not present
• Optimized hydraulic circuit with targeted pressure and increased flow rate: Yes
• Cold water connection: Yes
• Hot water connection: Optional (T4260AC)
• Demi water connection: Yes
• Drain pump: Yes
• Booster pump for demineralized water: Optional
• Peristaltic pump for dosing the liquid neutraliser: Yes
• Peristaltic pump for dosing liquid detergent: Yes
• Peristaltic pump for caustic soda: Optional
• Peristaltic pump for defoamer: Optional
• Possibility to install additional peristaltic pumps: Yes, up to 2
• Chemicals dosing: Optional
• Detergent level sensor: Optional
• Steam Condenser: Yes
• Water softener: Yes
• LED lighting in the washing chamber: Optional
• Acqua Stop: Optional
• Probe passage hole for validation: Yes
• Cabinet for detergents: Yes, for 2 canisters of 5 l
• Product dimensions (WxDxH mm): 900x605x850
