Thermostatic test chamber BIER-EO100

climatichumiditytemperature

Introduction
BIER-EO100 is designed to evaluate the resistance of biological indicators to ethylene oxide sterilization. It is intended for use by pharmaceutical and medical device manufacturers, regulatory authorities, third-party testing laboratories and biosafety facilities requiring traceable, repeatable resistance testing.

Features

• Automated operation with one-touch water filling, sterilization cycle initiation and exhaust control.
• Data integrity and traceability with real-time monitoring and secure recording to verify sterilization conditions.
• Safety features including interlock door protection, automatic pressure relief, temperature staging and negative-pressure airtightness testing routines.
• High operational stability with rapid concentration response (rise/decline ≤ 10 s).
• Customizable programs and user-level management with one-click generation of standardized test reports.

Applications

• Pharmaceutical production and quality control
• Medical device manufacturing and validation
• Biosafety and testing laboratories

Technical specifications

• Monitoring method: US-brand sensors
• Sterilizer concentration: 100–1200 mg/L
• Sterilization temperature: 29°C–65°C
• Relative humidity (RH): 30%–80%
• Pressure range: 4–20 kPa
• Concentration rising period: ≤ 10 s
• Concentration decline period: ≤ 10 s
• Time to vacuum: ≤ 60 s
• Leakage rate: ≤ 0.13 kPa/min
• Single sterilization quantity: 20 pcs
• Management authority: three user levels meeting GMP requirements
• Electronic signature: yes
• Sterilization curve output: yes
• Power supply: 380 VAC / 50 Hz
• Power: 5 kW
• Dimensions (W×H×D): 112 × 183 × 105 cm
• Weight: 700 kg
• Test report: included
