Thermostatic test chamber BIER-S100temperaturepressurelaboratory
Add to favorites
Compare this product
Characteristics
- Type
- thermostatic
- Controlled parameter
- temperature, pressure
- Applications
- laboratory, for the pharmaceutical industry, medical
- Configuration
- floor-standing
- Other characteristics
- automatic, high-performance, steam
- Capacity
5 l
(1.3 gal)- Temperature range
Min.: 110 °C
(230 °F)Max.: 145 °C
(293 °F)- Power
9,000 W
- External length
1,750 mm
(68.9 in)- External height
950 mm
(37.4 in)- External depth
780 mm
(30.71 in)
Description
Product Introduction
Designed to evaluate the resistance of biological indicators under pressure-steam sterilization. Suitable for pharmaceutical and medical device manufacturers, food and drug regulatory authorities, third-party testing laboratories and biosafety facilities.
Features
Specifications (table)
Sterilization Method: Pressure Steam Sterilization
Sterilization Target: Biological Indicator
Sterilization Chamber Volume: 5 L
Dimensions: 175.0 x 78.0 x 95.0 cm
Power Supply: AC 380V/50Hz
Weight: 150 kg
Electric Heating Power: 9 KW
Temperature Range: 110-145°C
Vacuum: 2 kPa
Time to Vacuum: <30 s
Come-up Period: ≤8 s
Sterilization Temperature Deviation: ±0.4°C
Come-down Period: ≤5 s
Time Accuracy: ±1 s
Leakage Rate: ≤0.1 kPa/min
Non-condensable Gas: ≤2.5%
Superheated Steam: ≤5°C
Steam Quality: ≥0.98
Sterilization Curve: Yes
Test Report: Yes
Three-level Management: Yes
Applications
Technical specifications
Designed to evaluate the resistance of biological indicators under pressure-steam sterilization. Suitable for pharmaceutical and medical device manufacturers, food and drug regulatory authorities, third-party testing laboratories and biosafety facilities.
Features
- Intelligent operation: one-click automatic water filling, sterilization and exhaust.
- Data integrity and traceability with real-time monitoring to verify sterilization outcomes.
- Safety functions: door-open protection, automatic pressure relief, staged temperature control, negative-pressure airtightness test and multi-level user management.
- High stability and precise control.
- Customizable program parameters and one-click test report generation.
Specifications (table)
Sterilization Method: Pressure Steam Sterilization
Sterilization Target: Biological Indicator
Sterilization Chamber Volume: 5 L
Dimensions: 175.0 x 78.0 x 95.0 cm
Power Supply: AC 380V/50Hz
Weight: 150 kg
Electric Heating Power: 9 KW
Temperature Range: 110-145°C
Vacuum: 2 kPa
Time to Vacuum: <30 s
Come-up Period: ≤8 s
Sterilization Temperature Deviation: ±0.4°C
Come-down Period: ≤5 s
Time Accuracy: ±1 s
Leakage Rate: ≤0.1 kPa/min
Non-condensable Gas: ≤2.5%
Superheated Steam: ≤5°C
Steam Quality: ≥0.98
Sterilization Curve: Yes
Test Report: Yes
Three-level Management: Yes
Applications
- Pharmaceutical manufacturers
- Medical device industry
- Biosafety laboratories
Technical specifications
- Sterilization Method: Pressure Steam Sterilization
- Sterilization Target: Biological Indicator
- Sterilization Chamber Volume: 5 L
- Dimensions: 175.0 x 78.0 x 95.0 cm
- Power Supply: AC 380V/50Hz
- Weight: 150 kg
- Electric Heating Power: 9 KW
- Temperature Range: 110-145°C
- Vacuum: 2 kPa
- Time to Vacuum: <30 s
- Come-up Period: ≤8 s
- Sterilization Temperature Deviation: ±0.4°C
- Come-down Period: ≤5 s
- Time Accuracy: ±1 s
- Leakage Rate: ≤0.1 kPa/min
- Non-condensable Gas: ≤2.5%
- Superheated Steam: ≤5°C
- Steam Quality: ≥0.98
- Sterilization Curve: Yes
- Test Report: Yes
- Three-level Management: Yes
