Laboratory peristaltic pump PC 610 select

Overview

• VACUU·SELECT vacuum controller with graphical user interface simplifies laboratory workflows
• Predefined applications save time and ensure reproducible results
• Application editor for custom process sequences (drag-and-drop)
• Suitable for evaporation of many high-boiling solvents
• High solvent recovery via exhaust vapor condenser for improved environmental performance

Product Details
The PC 600-series chemistry pumping units are engineered for electronically controlled evaporation and drying processes involving high‑boiling solvents. The unit uses the MD 4C NT three‑stage chemical diaphragm pump as the core and integrates the VACUU·SELECT controller providing manual set-point control, predefined vacuum programs and a customizable application editor. During solvent evaporation the controller continuously monitors pressure and switches to two‑point control when boiling is detected. The inlet separator (glass with protective coating) retains particles and liquid droplets. The exhaust vapor condenser enables near‑complete solvent recovery for economical recycling and reduced emissions.

Technical data and graphs
Max. pumping speed 50 Hz : 3.4 m3/h
Max. pumping speed 60 Hz : 2.2 cfm
Ultimate vacuum : 1.5 mbar / 1.1 torr
Ultimate vacuum with gas ballast : 3 mbar / 2.2 torr
Number of heads : 4
Number of stages : 3
Vacuum controller : VACUU·SELECT
Rated motor power : 0.25 kW
Rated motor speed 50/60 Hz : 1500 / 1800 min-1
Protection class IEC 60529 : IP 20
Dimensions L x W x H : 419 × 243 × 457 mm
Weight : 20.9 kg
Noise (sound pressure level) : 45 dBA
ATEX conformity : II 3/- G Ex h IIC T3 Gc X (internal atmosphere only)
Interface : Ethernet (RJ45): Modbus TCP / USB (Type A): data transfer & software update; RS-232 (adapter required)

Characteristics / technical specifications

• Model: PC 610 select
• Manufacturer / Brand: VACUUBRAND
• Base pump: MD 4C NT (3-stage chemical diaphragm pump)
• Ultimate vacuum (without gas ballast): 1.5 mbar (1.1 torr)
• Ultimate vacuum (with gas ballast): 3 mbar (2.2 torr)
• Max. pumping speed (50 Hz): 3.4 m3/h
• Max. pumping speed (60 Hz): 2.2 cfm
• Number of heads: 4
• Number of stages: 3
• Vacuum controller: VACUU·SELECT (graphical UI, predefined applications, application editor)
• Connections: Inlet/Outlet hose nozzle DN 8-10 mm; coolant 2 × DN 6-8 mm
• Max. back pressure (abs.): 1.1 bar
• Rated motor power: 0.25 kW
• Rated mains voltage range: 230 V / 50-60 Hz
• Operation ambient temperature: 10 °C to 40 °C
• Storage temperature range: -10 °C to 60 °C
• Protection class: IP 20
• Dimensions (L × W × H): 419 × 243 × 457 mm
• Weight: 20.9 kg
• Noise (50 Hz): 45 dBA
• ATEX: II 3/- G Ex h IIC T3 Gc X (internal atmosphere only)
• Items supplied: Pumping unit completely mounted, ready for use, with manual
