Transport sample container BTB-L series

for temperature-sensitive productsfor cold chainfor biohazards

Overview
Brand: BIOBASE
Product origin: CHINA
Delivery time: Within 7 days
Supply capacity: Factory Direct Supply
Models: BTB-L5, BTB-L6, BTB-L8, BTB-L12, BTB-L15, BTB-L20, BTB-L33, BTB-L55, BTB-L65, BTB-L85

Application
It can be used for the transportation of biological products requiring physical insulation, such as UN2814, UN2900, UN3373 biological samples, pathogenic microorganism (virus) species, blood, etc.

Available images (thumbnails shown on product page)
Multiple product images showing different capacities and internal layouts (images available on the product page).

Technical Parameters (selected rows from tables)
Models: BTB-L5 | BTB-L6 | BTB-L8 | BTB-L12 | BTB-L15
Capacity: 5L | 6L | 8L | 12L | 15L
Internal & External Materials: PP+PE
Insulation Material: PU
Temp. Resolution: 0.1℃
Manufacturing Process: Blow molding + injection molding, burr-free surface
Cooling Source Material: Sodium polyacrylate
Cooling Retention Time: Maintains an internal temperature of 2~8°C for over 24 hours at an ambient temperature up to 43°C
Sponge Test Tube Holder: Standard: 20 holes, compatible with 10ml test tubes; Optional: 11 holes, compatible with 20ml test tubes
Configuration examples (by model):
BTB-L5: Box*1, phase-change ice box(250ml)*2, absorbent cotton*1, digital thermometer*1, sponge test tube holder*1, 95KPa biosafety transport tank*1
BTB-L6: Box*1, phase-change ice box(400ml)*4, absorbent cotton*1, shoulder strap*1, digital thermometer*1, sponge test tube holder*1
BTB-L8: Box*1, phase-change ice box(400ml)*4, absorbent cotton*2, digital thermometer*1, sponge test tube holder*2, 95KPa biosafety transport tank*2
BTB-L12: Box*1, phase-change ice box(400ml)*6, absorbent cotton*2, shoulder strap*1, tray*1, digital thermometer*1, sponge test tube holder*2, 95KPa biosafety transport tank*2
BTB-L15: Box*1, phase-change ice box(400ml)*6, absorbent cotton*3, shoulder strap*1, tray*1, digital thermometer*1, sponge test tube holder*3, 95KPa biosafety transport tank*3

Models: BTB-L20 | BTB-L33 | BTB-L55 | BTB-L65 | BTB-L85
Capacity: 20L | 33L | 55L | 65L | 85L
Internal & External Materials: PP+PE
Insulation Material: PU
Temp. Resolution: 0.1℃
Manufacturing Process: Blow molding + injection molding, burr-free surface
Cooling Source Material: Sodium polyacrylate
Cooling Retention Time: Maintains an internal temperature of 2~8°C for over 24 hours at an ambient temperature up to 43°C
Sponge Test Tube Holder: Standard: 20 holes, compatible with 10ml test tubes; Optional: 11 holes, compatible with 20ml test tubes
Configuration examples (by model):
BTB-L20: Box*1, phase-change ice box(400ml)*9, shoulder strap*1, absorbent cotton*4, digital thermometer*1, tray*1, divider panel*1, sponge test tube holder*4, 95KPa biosafety transport tank*4
BTB-L33: Box*1, phase-change ice box(400ml)*11, absorbent cotton*5, digital thermometer*1, sponge test tube holder*5, 95KPa biosafety transport tank*5
BTB-L55: Box*1, phase-change ice box(400ml)*11, absorbent cotton*8, digital thermometer*1, sponge test tube holder*8, 95KPa biosafety transport tank*8
BTB-L65: Box*1, phase-change ice box(400ml)*15, absorbent cotton*12, digital thermometer*1, sponge test tube holder*12, 95KPa biosafety transport tank*12
BTB-L85: Box*1, phase-change ice box(400ml)*15, absorbent cotton*20, digital thermometer*1, sponge test tube holder*20, 95KPa biosafety transport tank*20

Size & Weight (selected rows)
BTB-L5 internal size (W*D*H): 200*142*165 mm | external size: 266*215*225 mm | package size: 380*270*300 mm | net weight: 12 kg | gross weight: 2.4 kg
BTB-L6 internal size: 240*145*180 mm | external size: 330*235*275 mm | package size: 380*270*300 mm | net weight: 2.5 kg | gross weight: 3.2 kg
BTB-L8 internal size: 295*167*168 mm | external size: 335*225*205 mm | package size: 380*270*300 mm | net weight: 2.2 kg | gross weight: 2.9 kg
BTB-L12 internal size: 325*170*225 mm | external size: 425*262*305 mm | package size: 460*355*360 mm | net weight: 4 kg | gross weight: 4.5 kg
BTB-L15 internal size: 363*203*244 mm | external size: 425*262*305 mm | package size: 460*355*360 mm | net weight: 4.3 kg | gross weight: 4.8 kg
BTB-L20 internal size: 380*245*230 mm | external size: 450*330*300 mm | package size: 490*360*340 mm | net weight: 4.8 kg | gross weight: 5.5 kg
BTB-L33 internal size: 480*250*290 mm | external size: 570*310*360 mm | package size: 585*325*390 mm | net weight: 5.5 kg | gross weight: 6.5 kg
BTB-L55 internal size: 590*335*320 mm | external size: 640*395*395 mm | package size: 670*430*430 mm | net weight: 8.3 kg | gross weight: 9.3 kg
BTB-L65 internal size: 540*425*315 mm | external size: 620*485*375 mm | package size: 640*505*395 mm | net weight: 9.8 kg | gross weight: 11 kg
BTB-L85 internal size: 580*465*320 mm | external size: 640*520*375 mm | package size: 650*540*400 mm | net weight: 13 kg | gross weight: 14.3 kg

Included accessories (examples)

• Phase-change ice boxes (quantity and volume vary by model)
• Absorbent cotton
• Digital thermometer
• Sponge test tube holder (standard or optional sizes)
• Shoulder strap, tray, divider panel (where specified)
• 95KPa biosafety transport tank (quantity varies by model)

Caractéristiques / spécifications techniques

• Material (internal & external): PP + PE
• Insulation: PU
• Temperature resolution: 0.1℃
• Manufacturing: Blow molding + injection molding, burr-free surface
• Cooling medium: Sodium polyacrylate (phase-change material)
• Cold retention: Keeps internal 2~8°C for over 24 hours at ambient up to 43°C
• Compatible test tube holders: Standard 20-hole (10 ml); Optional 11-hole (20 ml)
• Multiple model sizes from 5 L to 85 L (BTB-L series)
• Typical configuration: product box plus phase-change ice packs, digital thermometer, absorbent cotton and accessories as specified per model
