Hospital freezer BDF-86V168T

for biobanksmedicalfor vaccines

General information

• Brand: BIOBASE
• Product origin: China
• Delivery time: Within 7 days
• Supply capacity: Factory direct supply
• Model: BDF-86V168T / BDF-86V348T

Introduction
The BDF-86V series -86°C ultra-low temperature freezer provides a controlled extreme-low temperature environment for long-term storage of temperature-sensitive biological samples and materials used in research, medical and biotechnology facilities. It is designed for reliable temperature control and remote monitoring interfaces required in professional laboratory and clinical settings.

Technical parameters
Model: BDF-86V168T / BDF-86V348T
Capacity: 168 L / 348 L
Temperature range: -40 ~ -86 °C
Temperature accuracy: 0.1 °C
Temperature uniformity: ±4 °C
Temperature stability: ≤6 °C
Recovery time (to -75 °C at 25 °C ambient): ≤30 min
Cooling time (to -80 °C at 25 °C ambient): ≤7 h
Control system: Microprocessor control
Display: LCD
Alarms: High/low temperature, thermostat fault, door switch, power failure (72 h)
Refrigeration type: Direct-cooling
Refrigerant: R290/R170, 183 g (168 L) / R290/R170, 308 g (348 L)
Compressor: International brand compressor / 2
Condenser & evaporator: Built-in coil type; copper tube and aluminum fin
Defrost: Manual defrost
Insulation: Polyurethane cyclopentane foam
Internal material: SUS304 stainless steel
External material: Sprayed steel plate
Doors: Outer door: cyclopentane monomer foam ×1; Inner door: cyclopentane monolithic foam, stainless steel inner doors ×3 (168 L) / ×2 (348 L)
Power consumption: 830 W (168 L) apparent power: 1386 VA; 915 W (348 L) apparent power: 1386 VA
Power supply: AC 220 V, 50 Hz (standard); 110/220 V, 60 Hz (optional)
Casters: Yes
Shelves: 2 (168 L) / 3 (348 L)
Standard interfaces/accessories: Test port ×2; USB; RS485
Optional accessories: Liquid nitrogen backup system; temperature recorder
Internal size (W×D×H): 465×455×820 mm (168 L) / 490×612×1150 mm (348 L)
External size (W×D×H): 844×807×1594 mm (168 L) / 869×989×1924 mm (348 L)
Package size (W×D×H): 1000×970×1790 mm (168 L) / 1020×1180×2130 mm (348 L)
Net weight: 196 kg (168 L) / 264 kg (348 L)
Gross weight: 253 kg (168 L) / 332 kg (348 L)

Features / technical specifications

• Model series: BDF-86V
• Operating range: -40 to -86 °C with 0.1 °C control resolution
• Microprocessor control with LCD and multi-level alarms
• Direct-cooling system using R290/R170 refrigerants
• Inner chamber in SUS304 stainless steel; robust sprayed steel exterior
• Cyclopentane polyurethane insulation for low thermal loss
• Standard test ports and digital interfaces for monitoring and integration
• Available in two capacities: 168 L and 348 L

Accessories

• Standard: Test port ×2, USB interface, RS485 interface
• Optional: Liquid nitrogen backup system, temperature recorder, alternative power configurations

Applications
Suitable for laboratories, biobanks, hospitals, research institutes and pharmaceutical facilities requiring stable ultra-low temperature storage for biological samples, vaccines, cells, tissues and reagents.
