High-purity nitrogen generator Whisper 0-40

for LC/MSfor mass spectrometersfloor-standing

Overview
The Whisper 0-40 Hybrid Nitrogen Generator supplies nitrogen for LC/MS workflows that require filtered, dried air and controlled gas flows for solvent evaporation and electrospray operations. The membrane separation module delivers nitrogen with a low pressure drop (1 barg), enabling use with existing dry, oil-free compressed air sources.

Key features

• Flow rates: curtain gas 40 L/min @ 7 barg (100 psig); exhaust gas 25 L/min @ 4 barg (60 psig); source gas 22 L/min @ 7 barg (100 psig)
• Nitrogen purity: 97%
• Maximum outlet pressure: 7 barg (100 psig)
• Minimal maintenance; no electrical supply required
• Integrated economy mode
• Proprietary membrane technology
• Part number: DB-WN2-0-40-HY
• 2 year standard warranty

Applications

• Supply gas for LC/MS instruments (curtain, nebulizing, sheath, shield, electrospray)
• Evaporation and solvent removal in sample preparation
• Compatible with SCIEX LC/MS, SHIMADZU LC/MS and similar systems

Part number
DB-WN2-0-40-HY

Technical specifications

• Curtain gas flow rate L/min - Nitrogen: 40 @ 7 barg (100 psig)
• Exhaust gas flow rate L/min - dry air: 25 @ 4 barg (60 psig)
• Source gas flow rate L/min - dry air: 22 @ 7 barg (100 psig)
• Nitrogen purity at max flow rate: 97%
• Dew point: -40°C (-40°F)
• Outlet pressure (barg / psig): 7 (100)
• Inlet pressure (barg / psig): 8.5 to 10 (123 to 160)
• Actual inlet air requirement (liters/min): 197
• Recommended compressor air requirements (liters/min): 394
• Pressure drop (barg / psig): 1.5 (22)
• Inlet air quality: Clean dry compressed air ISO8573-1:2010 Class 1.2.1
• Technology: Membrane
• Warm up time: None
• Electrical supply: None
• Noise level: None
• Product dimensions (mm / in): 480W x 1300H x 300D (18.9W x 51H x 11.8D)
• Product weight (kg / lb): 25 (55)
• Shipping dimensions (mm / in): 1600W x 400H x 590D (63W x 15.7H x 23.2D)
• Shipping weight (kg / lb): 32 (71)
• Operating temperature (°C / °F): 15 to 35 (59 to 95)
• Inlet connection: 3/8" G
• Outlet connection: 6 mm or 1/4" OD compression
• Certification: CE

Compressor & installation

• Actual inlet air required: 197 L/min; recommended compressor capacity: 394 L/min
• Inlet pressure: 8.5–10 barg (123–160 psig)
• Pressure drop across system: 1.5 barg (22 psig)
• Inlet air quality must meet ISO8573-1:2010 Class 1.2.1 (clean, dry, oil-free)
• Inlet/outlet connections as specified in technical data

Warranty & support

• 2 year standard warranty
• Minimal routine maintenance; replaceable membrane modules as required
• Spare parts and service available through authorised distributors
