High-purity nitrogen generator DB-EVO

laboratoryfor LC/MSfor spectrometry

Overview
The Mistral Evolution Gas-Station DB-EVO-GS is a dedicated nitrogen and dry air generator designed for laboratory use with microwave systems such as the Agilent MP AES 4100/4200. Using proven pressure swing adsorption (PSA) with a carbon molecular sieve, it produces nitrogen and dry air simultaneously to reduce instrument warm-up and stabilize analysis conditions. Its specialized insulation allows installation close to the instrument or under the bench for a compact laboratory footprint.

Features

• Flow rate up to 25 L/min (nitrogen)
• Nitrogen purity: 99.5%
• Maximum outlet pressure: 7 barg (100 psig)
• Oil-free compressor options and low noise operation
• Proprietary carbon molecular sieve PSA technology
• Complete plug-and-play solution for LC/MS and MP AES setups
• Standard 2-year warranty

Applications

• Microwave Plasma Atomic Emission Spectrometry — AGILENT MP AES 4100 & 4200

Options

• N/A

Specifications
Nitrogen flow rate: 25 L/min @ 5.5 barg (80 psig)
Air flow rate: 35 L/min @ 5.5 barg (80 psig)
Nitrogen purity: 99.5%
Dewpoint: -40 °C (-40 °F)
Outlet pressure: 7 barg (100 psig)
Technology: Carbon molecular sieve (PSA)
Warm up time: 20 minutes
Electrical supply: 220–240 V 50 Hz or 110–120 V 60 Hz (NEMA 5-20P)
Power consumption: 2700 W
Product dimensions (W x H x D): 482 x 641 x 1235 mm (18.9 x 25 x 48 in)
Product weight: 110 kg (243 lb)
Shipping dimensions (W x H x D): 550 x 800 x 940 mm (21.6 x 31.4 x 37 in)
Shipping weight: 141 kg (311 lb)
Operating temperature: 15 to 35 °C (59 to 95 °F)
Outlet connection: 2 x 6 mm OD compression or 1/4"
Certification: CE, FCC, MET (UL and CSA compliant)

Part numbers
Part# DB-EVO-GS-EU (220V/50Hz)
Part# DB-EVO-GS-EU (115V/60Hz NEMA 5-20P)
