Dry nitrogen generator Mistral P-E

high-puritylaboratoryfor LC/MS

Overview
The Mistral Evolution Gas Station P-E is a dedicated nitrogen generator designed for use with the Microwave Agilent 4100MP system. It uses proven pressure swing adsorption (PSA) technology to produce nitrogen and dry air simultaneously, enabling faster instrument stabilization and quicker readiness. Compact insulation allows installation next to the instrument or under a laboratory bench.

Mistral Evolution Gas Station Features

• Flow rate up to 25 l/min
• Nitrogen purity 99.5%
• Outlet pressure up to 7 bar (100 psi)
• Oil-free, low-noise compressor options
• Carbon molecular sieve (proprietary) technology
• Complete plug-and-play LC/MS compatible solution
• 2 year standard warranty

Part Numbers
Part# DB-EVO-GS-PE-EU (220V/50Hz) Part# DB-EVO-GS-PE-EU (115V/60Hz NEMA 5-20P)

Applications

• Microwave Plasma Atomic Emission Spectrometry: AGILENT MP AES 4100 & 4200

Technical specifications

• Nitrogen flow rate: 25 lpm @ 5.5 bar (80 psi)
• Air 1 - flow rate: 35 lpm @ 5.5 bar (80 psi)
• Nitrogen purity: 99.5%
• Dewpoint: -40°C
• Outlet pressure: 7 bar (100 psi)
• Technology: Carbon molecular sieve (PSA)
• Warm up time: 20 minutes
• Electrical supply: 220-240V 50Hz / 110-120V 60Hz (NEMA 5-20P)
• Power consumption: 2500 W
• Product dimensions: 482 W x 641 H x 1235 D mm (18.9 x 25 x 48 in)
• Product weight: 110 kg (243 lb)
• Shipping dimensions: 550 W x 800 H x 940 D mm (21.6 x 31.4 x 37 in)
• Shipping weight: 141 kg (311 lb)
• Operating temperature: 15 to 35 °C (59 to 95 °F)
• Outlet connection: 2 x 6 mm OD compression or 1/4"
• Certification: CE, MET, FCC
