Heating oven M 56

for temperature testingfor general applicationslaboratory

Product overview
The M series material test chamber M 56 is designed for material testing and aging tests with a temperature range up to +300 °C. Forced-convection airflow and APT.line™ preheating ensure reproducible temperature conditions across the usable space. The unit provides versatile programming, data logging and computer interface options for laboratory and production environments.

Benefits

• Uniform temperature distribution via APT.line™ technology
• Reproducible test conditions independent of sample size and quantity
• Thermal insulation to reduce operating energy demand
• Extensive programming and data export options

Key features

• Temperature range: from +23 °C above ambient temperature to +300 °C
• High temperature accuracy using APT.line™ technology
• Reinforced fan with adjustable speed for high air change rates
• Electromechanical control of exhaust air flap
• Intuitive touchscreen controller with time-segment and real-time programming
• Failsafe function with backup Pt100 sensor
• Computer interface: Ethernet; internal data logger with USB export in open format
• Standard fittings: 2 chrome-plated racks (std.), expandable to 4
• Safety devices: adjustable temperature limiter Class 2 and selectable temperature monitor Class 3.1 (DIN 12880) with visual/acoustic alarm

Technical specifications

• Article number: 9010-0371
• Designation: M056-230V
• Model version: Standard
• Temperature uniformity at 150 °C: 1.4 ± K
• Temperature fluctuation at 150 °C: 0.2 ± K
• Heating time to 150 °C: 9 min
• Recovery time after 30 s door opening at 150 °C: 4 min
• Air change rate at 100 °C: 175 x/h
• Rated voltage: 230 V; Power frequency: 50/60 Hz; Nominal power: 2 kW; Fuse: 10.0 A; Phase: 1~
• Internal volume: 59 L; Interior dimensions (W×H×D): 400 × 440 × 335 mm
• Housing (W×H×D): 560 × 622 × 596 mm; Net weight (empty): 43 kg
• Load per rack: max. 30 kg; Permitted total load: 70 kg
• Wall clearance back / side: 160 mm / 100 mm
• Number of doors: 1; Number of shelves (std./max.): 2 / 4
• Sound-pressure level: 46 dB(A)
• Energy consumption: 210 Wh/h (100 °C); 330 Wh/h (150 °C)
