Orthosis AM-OSN-L-01

forearm splintwrist splintpalmar resting splint

Product name
Children wrist splint AM-OSN-L-01 offers wrist, hand and forearm immobilization and stabilization.

Product Features
I CLASS MEDICAL PRODUCT
ANATOMIC WRIST SPLINT
WRIST & FOREARM BRACE

Wrist sprain
Wrist sprain is a common injury among children, usually caused by a fall on an outstretched arm leading to hyperextension and damage to soft tissues and ligaments. Swelling, pain and limited mobility occur. Splinting, ice and rest are recommended; the paediatric wrist brace AM-OSN-L-01 is designed for this purpose.

Purpose of use

• wrist sprain/strain
• wrist dislocation
• wrist inflammation
• overused wrist and II-V fingers joints
• joint capsule injury
• stress fracture
• II-V fingers ligaments injury
• wrist rheumatoid arthritis (RA)

PRODUCT’S DESCRIPTION
The brace has a design providing wrist support. Children wrist splint AM-OSN-L-01 keeps the wrist in a neutral position required for proper healing. The splint is made of the innovative textile AirSanmed II™. AirSanmed II™ is a multi-layered intelligent orthopedic fabric: washable, perforated and laminated with off-loading foam and soft comfort foam, laminated with breathable cotton certified OekoTex Standard100 and skin-friendly. The fabric reduces pressure of aluminum stays and splints and ensures breathability and comfort.

ALLOWABLE DISINFECTANTS
Spray the surface of the device with disinfectant, leave for activation, then wash and dry.
2-propanol | 35%
1-propanol | 25%
Ethanol | 10%
Alkyl Dimethyl Benzyl Ammonium Chloride | 0.2%
Glucoprotamine | 25%

The paediatric wrist brace includes a malleable aluminum palm splint which maintains the hand in neutral position and prevents dorsal and palmar flexion. The splint immobilizes the wrist, offering neutral joint position for healing after fracture or injury. The palmar part involves fingers II-V and offers their proper position; the brace is equipped with a wraparound metacarpal strap preventing involuntary finger flexion. The dorsal side of the forearm is immobilized with two orthopaedic stays preventing brace sliding. Velcro closures provide a wide range of circumferential adjustment and allow use in case of hand and forearm swelling. The brace is easy to apply and remove for skin and tissue inspection and may be used in case of Volkmann contracture.

AVAILABLE SIZES
Size 1 | Wrist circumference 10–12 cm | Typical age 3–5 years
Size 2 | Wrist circumference 12–15 cm | Typical age 5–12 years
Right and left hand specific.
Total length of the product: 1: 21 cm | 2: 25 cm

Downloads
Declaration of Conformity EC
Manual

Technical specifications

• Code: AM-OSN-L-01
• Trade Name: WRIST ORTHOSIS
• Model: AM-OSN-L-01
• Indications: wrist sprain/strain, dislocation, inflammation, overuse, joint capsule injury, stress fracture, II-V finger ligament injuries, wrist RA
• Material: AirSanmed II™ multi-layered orthopedic textile (breathable, washable, laminated with off-loading foam and soft comfort foam, OekoTex Standard100 certified cotton)
• Palm splint: malleable aluminum palm splint maintaining neutral hand position (prevents dorsal/palmar flexion)
• Finger support: palmar part involves fingers II–V; wraparound metacarpal strap to prevent involuntary finger flexion
• Forearm support: 2 dorsal orthopaedic stays to prevent sliding
• Closures: Velcro circumferential adjustment (accommodates swelling)
• Sizes: 1 (10–12 cm wrist, length 21 cm) and 2 (12–15 cm wrist, length 25 cm)
• Laterality: right and left specific
• Medical classification: Class I medical device (Regulation (EU) 2017/745)
