Wrist brace FIX-KG-18

wrist splintwrist orthosisforearm splint

Short description
Pediatric upper-extremity brace FIX-KG-18 immobilizes the wrist and adjacent joints to support treatment of dislocations and related injuries. Made from breathable AeroSpace II™ fabric and fitted with a low-profile, shapeable aluminum splint covered to reduce pressure, the device extends from the metacarpals to the forearm, stabilizes the wrist in a neutral position while allowing free finger motion. Supplied with three Velcro straps for quick application and adjustment. Suitable for daily immobilization and as an alternative to a traditional cast.

Key advantages

• Class I medical device
• Waterproof
• Double-sided design
• Full range of adjustment (self-gripping outer layer)
• Wrist and forearm immobilization
• Anatomic, shapeable aluminum wrist splint

Purpose of use

• Wrist fractures
• Wrist sprain/strain
• Wrist dislocation
• Wrist inflammation
• Overuse injuries of the wrist
• Joint capsule injury
• Triangular Fibrocartilage Complex (TFCC) injury
• Stress fracture
• Wrist rheumatoid arthritis (RA)
• Cerebral palsy (CP)

Material description
AeroSpace II™ is a distance-elastic 3D knitted fabric composed of two facing layers with an interlacing that provides appropriate thickness and pressure relief. The knit uses polyester yarn for mechanical strength and spandex for elasticity. AeroSpace II™ features an external self-gripping layer for easy adjustment, very low weight, high flexibility, an open structure for sweat drainage and air circulation, consistent compression and fit, and a 3D structure that supports orthopaedic splints while remaining soft to the touch.

Available sizes
Size | Arm circumference (A) | Forearm length | Typical age | How to measure
1 | 10–16 cm | min 11 cm | 2–6 years | (measurement illustration available)
2 | 13–20 cm | min 15 cm | >5 years | (measurement illustration available)
Fits both hands.
Total length of the product:
1: 16 cm
2: 18 cm

Downloads (documents related to the product)
Declaration of Conformity EC
Manual
Setting up (product PDF)

Technical specifications

• Code: FIX-KG-18
• Trade Name: UPPER-EXTREMITY SUPPORT
• Model: FIX-KG-18
• Intended use: immobilization and stabilization of wrist and forearm for paediatric patients (dislocation, fractures, neurological conditions such as cerebral palsy, inflammation, overuse injuries, TFCC injuries, stress fractures, RA)
• Materials: AeroSpace II™ (3D knitted polyester/spandex fabric), aluminum splint (lightweight, low-profile, shapeable)
• Splint: lightweight low-profile aluminum, covered to reduce pressure, extends from metacarpals to forearm
• Closure: set of 3 Velcro straps for application and adjustment
• Design: allows free finger movement while immobilizing the wrist
• Water resistance: waterproof
• Adjustment: double-sided and full range of adjustment (self-gripping outer layer)
• Classification: Class I medical device
• Fits: both left and right hand
• Available sizes and product lengths as listed above
